Do typical section sheets show elevation views of the proposed road? no The directional arrow is found on the ________ view of a plan and profile sheet plan Which sheet shows the shape of the road's side slopes and ditches? section sheet Which sheets show a cross-section view of the road superimposed on the natural ground line? cross-section sheets Name the other sheet that shows the shape of the road from a cross-section view. section sheet (more dimensions and slope data) Revision numbers to Roadway and Traffic Design Standards appear in the ________________________ corner of that sheet. lower right To find where in Florida the project is located, you would look at the __________________ in the _________________corner of the _______________ state map; upper right; key sheet An index to all sheets in the plan set is given on the ____________ key sheet 8/8/25, 8:35 AM FDOT Plan Reading Exam Flashcards | Quizlet with typical shape and dimensions of proposed road section sheets Cover sheet which identifies the project and shows its location key sheet Shows details of roadway items usable on many projects roadway and traffic design standards Shows tabulated quantities of all materials and work required for construction summary of quantities sheet Shows two views of the roadway - a plan view and an elevation view plan and profile sheets Shows the natural ground line and the template of the proposed roadway at frequent points along the roadway cross section sheet Plan sheet with details of road signs to be erected signing and pavement making plans Plan sheet with the details of the electrical wiring of traffic signals signalization plans Plan sheet with details of bridges to be constructed on the project structures plan Plan sheet with cross section views of the proposed roadway roadway plans 8/8/25, 8:35 AM FDOT Plan Reading Exam Flashcards | Quizlet Sheet number prefix - S signing and pavement making plans Sheet number prefix - T signalization plans Sheet number prefix any letter other than I,L,O,Q,S or T structures plans Sheet numbers without prefixes are in the roadway plans Which sheets do not have sheet identification boxes in their upper right corners? roadway and traffic design standards Sheet names appear in the _______________ corners of most types of sheets. lower right
