Lesson 5 engine cooling system

ENGINE COOLING SYSTEM f.mf.m f.mf.m




A system, which controls the engine temperature, is known as the engine cooling system.
f.mf.m f.mf.m f .mf. m f. mf. m f. mf.m f.mf. m f.mf .m f.mf .m f.mf. m f. mf.m f. mf.m f. mf.m f.mf .m




NECESSITY OF COOLING SYSTEM f.mf.m f.mf.m f.mf.m




The cooling system is provided in the IC engine for the following reasons:
f. mf.m f.mf. m f.mf.m f. mf.m f. mf.m f. mf.m f. mf.m f.mf .m f.mf. m f.mf. m f.mf. m f .mf. m




i. The temperature of the burning gases in the engine cylinder reaches up to 1500 to 2000°C, which is f. mf.m f. mf.m f.m f.m f. mf.m f.m f.m f.m f.m f.m f.m f. mf.m f .mf. m f.mf .m f .mf. m f.m f.m f.mf. m f.mf .m f .mf. m f.m f.m f.mf .m




above the melting point of the material of the cylinder body and head of the engine. (Platinum, a
f.mf.m f.m f.m f.m f.m f. mf.m f .mf. m f. mf.m f. mf.m f.mf. m f. mf. m f. mf.m f. mf.m f. mf. m f. mf.m f. mf.m f.mf .m f.mf .m f.m f.m f.mf. m




metal which has one of the highest melting points, melts at 1750 °C, iron at 1530°C and aluminium
f.mf.m f. mf.m f. mf. m f. mf.m f.mf .m f. mf. m f. mf.m f.mf. m f.mf. m f.mf.m f.mf .m f. mf.m f. mf.m f.m f.m f .mf. m f. mf.m f.mf. m f. mf.m




at 657°C.) Therefore, if the heat is not dissipated, it would result in the failure of the cylinder
f.mf.m f. mf.m f .mf. m f. mf. m f.mf .m f.m f.m f .mf. m f.m f.m f. mf.m f. mf. m f.mf .m f. mf.m f. mf.m f. mf. m f.mf. m f. mf. m f. mf.m f .mf. m




material. f.mf.m




ii. Due to very high temperatures, the film of the lubricating oil will get oxidized, thus producing carbon f.mf .m f.mf. m f .mf. m f. mf.m f.mf. m f.mf .m f. mf.m f. mf.m f. mf.m f.m f.m f.m f.m f. mf.m f. mf.m f. mf.m f. mf.m f.m f.m




deposits on the surface. This will result in piston seizure.
f.mf.m f.mf.m f. mf.m f. mf.m f.mf .m f. mf.m f. mf.m f.m f.m f.mf .m f.mf. m




iii. Due to overheating, large temperature differences may lead to a distortion of the engine f.mf.m f .mf. m f.mf. m f.m f.m f .mf. m f. mf.m f.mf.m f. mf. m f.mf. m f. mf.m f.m f.m f.mf.m f.mf .m




components due to the thermal stresses set up. This makes it necessary for, the temperature
f.mf.m f.mf .m f .mf. m f. mf.m f. mf.m f.mf .m f.mf. m f.mf. m f. mf. m f.m f.m f. mf. m f.mf. m f.mf. m f. mf.m f. mf.m




variation to be kept to a minimum. f.mf.m f.mf. m f. mf.m f .mf. m f. mf.m f.mf. m f.mf. m




iv. Higher temperatures also lower the volumetric efficiency of the engine. f. mf.m f.mf. m f .mf. m f .mf. m f .mf. m f. mf.m f.mf.m f. mf.m f.m f.m




REQUIREMENTS OF EFFICIENT COOLING SYSTEM f.mf.m f.mf.m f.mf.m f.mf.m




The two main requirements of an efficient cooling system are:
f. mf.m f. mf.m f. mf. m f. mf.m f.mf. m f.m f.m f. mf.m f. mf.m f.mf. m




I. It must be capable of removing only about 30% of the heat generated in the combustion chamber.
f.mf.m f.mf. m f. mf.m f. mf.m f. mf.m f. mf. m f. mf. m f. mf. m f.mf. m f. mf.m f .mf. m f. mf.m f .mf. m f.mf. m f.m f.m f. mf. m




Too much removal of heat lowers the thermal efficiency of the engine.
f.mf.m f .mf. m f. mf. m f.m f.m f .mf. m f.mf .m f.mf. m f. mf. m f.m f.m f.mf.m f. mf.m f.m f.m




II. It should remove heat at a fast rate when the engine is hot. During the starting of the engine, the
f.mf.m f.m f.m f. mf. m f.mf. m f.m f.m f.mf. m f.mf.m f .mf. m f. mf. m f. mf. m f. mf. m f.mf.m f.mf. m f.m f.m f.mf .m f .mf. m f.m f.m f.mf. m f.mf.m




cooling should be very slow so that the different working parts reach their operating temperatures in
f.mf.m f.mf .m f .mf. m f.m f.m f .mf. m f.mf. m f. mf.m f. mf.m f. mf.m f.mf. m f.mf .m f.mf .m f.mf. m f.m f.m f.mf .m f. mf.m




a short time.
f.mf.m f. mf.m f. mf.m




TYPES OF COOLING SYSTEM f.mf.m f.mf.m f.mf.m




There are two types of cooling systems: f.m f.m f .mf. m f.mf. m f.mf .m f. mf. m f.mf .m




i. Air cooling system and f.mf. m f.m f.m f.mf.m




ii. Water-cooling system. f.mf .m




AIR COOLING SYSTEM f.mf.m f.mf.m




This method is used mainly for small single cylinder engines, such as those motorcycles, scooters, small
f.mf.m f.mf. m f.mf. m f .mf. m f. mf.m f.mf .m f.m f.m f.mf .m f. mf.m f.mf. m f.mf .m f. mf.m f.mf .m f.mf.m f.mf.m




cars and small aircraft engines where the forward motion of the machine gives good velocity to cool the
f.mf.m f.m f.m f.mf. m f. mf.m f. mf. m f .mf. m f. mf.m f. mf.m f. mf.m f .mf. m f. mf. m f .mf. m f. mf.m f.mf .m f.m f.m f.mf.m f .mf. m f .mf. m




engine.
f.mf.m




In this type of cooling system (shown in Figure 1), the heat, which is conducted to the outer parts of the
f.mf.m f.mf .m f. mf.m f.mf. m f .mf. m f.mf.m f. mf. m f.mf .m f.mf.m f. mf.m f.mf. m f.mf. m f.mf. m f.mf.m f. mf. m f.mf. m f. mf.m f.mf .m f.mf. m f.mf. m




engine, is radiated and conducted away by the stream of air, which is obtained from the atmosphere.
f.mf.m f.mf .m f.mf. m f. mf. m f.mf. m f.mf .m f.mf .m f.m f.m f.mf. m f.mf .m f. mf.m f.mf. m f.mf. m f.mf.m f. mf.m f.mf. m f.mf.m f.mf. m




Cooling is done by directing a blast of air around the cylinder and cylinder head, both of which are finned.
f.mf.m f. mf.m f.mf. m f. mf.m f. mf.m f. mf.m f .mf. m f .mf. m f .mf. m f. mf.m f.m f.m f. mf. m f.m f.m f. mf.m f.mf. m f.mf .m f.mf. m f.mf. m f.mf .m f.m f.m




The fins are metallic ridges, which are formed during the casting of the cylinder and cylinder head. This
f.mf.m f. mf.m f.mf. m f.mf .m f.mf. m f.mf. m f.mf.m f.mf. m f.mf.m f. mf.m f.mf. m f.mf. m f.mf. m f. mf.m f.mf. m f.mf .m f.m f.m f.mf.m




finning provides a large surface areas through which the heat can spread and from which heat is taken
f.mf.m f.mf. m f. mf.m f. mf.m f. mf.m f.m f.m f.mf. m f.mf. m f.m f.m f.m f.m f. mf.m f. mf.m f. mf.m f.mf. m f.mf. m f.m f.m f.mf .m f.mf .m




away by cooling air. The blast of air is created by fitting a blower fan on the engine flywheel and this is
f.mf.m f.mf.m f.mf.m f. mf.m f.mf. m f.mf. m f.mf. m f.mf. m f. mf.m f.mf .m f.mf. m f.mf. m f.mf. m f.mf .m f.mf. m f. mf.m f.m f.m f.mf. m f. mf.m f.mf. m f.mf. m f.mf. m




1

, f.mf.m encased in a cowling which extends over and around the cylinder. Air is drawn in by the blower and directed
f.m f.m f.m f.m f. mf.m f.mf .m f. mf. m f .mf. m f.mf .m f.mf. m f.mf .m f.mf .m f.mf .m f.mf. m f.m f.m f.mf. m f.mf. m f. mf. m f .mf. m f. mf.m f. mf.m




f.mf.m over the cylinder to cool it.
f .mf. m f. mf. m f .mf. m f. mf.m f.mf .m f.mf. m




f.mf.m




Figure 1: Air cooling system f.mf.m f.mf.m f.mf.m f.mf.m




Overheating of this type of engine will take place if the spaces between the fins are allowed to become f.mf .m f.m f.m f .mf. m f .mf. m f .mf. m f. mf.m f .mf. m f .mf. m f. mf.m f.mf. m f. mf.m f.m f.m f.m f.m f. mf.m f.mf .m f.m f.m f .mf. m f .mf. m




choked with dirt. The amount of heat carried off by the air-cooling depends upon the following factors:
f.mf.m f. mf. m f.mf. m f.m f.m f. mf.m f.m f.m f.mf. m f.mf .m f.mf .m f.mf.m f.mf. m f .mf. m f.m f.m f. mf.m f. mf.m f. mf.m f. mf.m




i. The total area of the fin surfaces, f. mf.m f.mf. m f.mf. m f. mf.m f. mf.m f.mf. m




ii. The velocity and amount of the cooling air and f. mf.m f.mf.m f. mf. m f. mf.m f.mf. m f .mf. m f.m f.m f. mf.m




iii. The temperature of the fins and of the cooling air. f. mf.m f.m f.m f .mf. m f .mf. m f.mf. m f. mf.m f.mf .m f.mf. m f. mf.m




Advantages of Air Cooled Engines f .mf.m f.mf .m f.mf.m f.mf.m




Air cooled engines have the following advantages:
f.mf. m f.m f.m f.m f.m f. mf.m f. mf.m f.m f.m




i. Its design of air-cooled engine is simple. f.mf.m f.mf .m f. mf. m f.m f.m f. mf.m f. mf. m




ii. It is lighter in weight than water-cooled engines due to the absence of water jackets, radiator,
f.mf.m f.mf.m f. mf.m f.mf. m f.mf .m f.mf. m f. mf. m f.mf.m f.mf. m f.mf. m f. mf.m f. mf.m f.mf. m f.mf .m f.mf.m




circulating pump and the weight of the cooling water.
f.mf.m f. mf.m f.mf .m f .mf. m f. mf. m f. mf.m f.mf .m f.mf. m f. mf.m




iii. It is cheaper to manufacture. f.mf.m f.mf .m f. mf.m f.mf. m




iv. It needs less care and maintenance. f.mf.m f. mf.m f.mf. m f.mf. m f. mf.m




v. This system of cooling is particularly advantageous where there are extreme climatic conditions in
f.mf.m f.mf. m f.mf .m f. mf.m f.m f.m f. mf.m f.m f.m f. mf.m f.mf .m f. mf.m f. mf.m f.mf. m f.mf. m




the arctic or where there is scarcity of water as in deserts.
f.mf.m f. mf.m f.mf.m f .mf. m f. mf.m f.mf. m f.mf .m f.mf.m f.mf. m f .mf. m f.m f.m f. mf. m




vi. No risk of damage from frost, such as cracking of cylinder jackets or radiator water tubes.
f.mf.m f.mf.m f.mf .m f. mf.m f. mf.m f.mf.m f .mf. m f. mf.m f.mf .m f.mf. m f .mf. m f.mf.m f .mf. m f.mf .m f.mf. m




WATER COOLING SYSTEM f.mf.m f.mf.m
