NCCER Core - Module 5 Exam 2025 Questions & Answers with 100% Correct Answers | Verified

Which plan shows layout of HVAC systems - Mechanical Plan Site plan show the location of a building from an________ view - Aerial View Electrical plans can include ___________ plans - Lighting drawings that show the design of the project - Architectual Plans drawings that show the location of the building on the site from an aerial view. Including contours, trees, construction features and dimensions. - Civil Plans (Site Plans) engineered drawings that show the mechanical systems, such as motors and piping - Mechanical Plans A set of engineered drawings used to support the architectural design. - Structural Plans ____________ are used for work that has to do with construction in or on the earth. a. Architectural plans b. Construction drawings c. Civil drawings d. Work plans - a Which type of drawing would indicate the material to be used for building the walls of a structure? a. Work plans b. Civil plans
