Asphalt-concrete Exam Questions With
Correct Answers.
A mechanical device on an asphalt batch plant, consisting of paddles attached to rotating shafts,
for mixing aggregates and asphalt cement.
Select one:
a. Hot oil heater
b. Pug mill
c. Weigh hopper
d. Intake Hopper - Answer✔pug mill
The top or riding surface of a pavement structure.
Select one:
a. Surface course
b. Lift (mat)
c. Leveling course
d. Binder Course - Answer✔surface course
The process of shaping the concrete surface to correct elevation by striking off the excess
concrete.
Select one:
a. Contraction Joints
b. Penetration Test (AASHTO)
c. Screeding
d. Breakdown - Answer✔screeding
Are a blend of asphalt cement and a fuel product.
1|Page
, ©BRIGHSTARS 2024/2025 ALL RIGHTS RESERVED.
Select one:
a. Hot-mix Asphalt
b. Windrow
c. Asphalt Cutbacks
d. Flexible Pavement - Answer✔asphalt cutbacks
Where the paving machine rides on steel forms that are set to the proper line and grade for the
finished slab.
Select one:
a. Nipped
b. Breakdown
c. Formed
d. Frequency - Answer✔formed
In concrete, the chemical reaction between cement and water. The features of this reaction are a
change in matter, in energy level, and in rate of reaction.
Select one:
a. Hydration
b. Expansion Joints
c. Dwell Time
d. Hveem - Answer✔hydration
By remixing the asphalt concrete, reduced thermal segregation creates uniform stiffness that
allows for rougher pavement construction.
Select one:
True
False - Answer✔false.
By remixing the asphalt concrete, reduced thermal segregation creates uniform stiffness that
allows for SMOOTHER pavement construction
Smaller commercial aggregate plants are the major source of crushed stone for the construction
industry in metropolitan areas.
2|Page
, ©BRIGHSTARS 2024/2025 ALL RIGHTS RESERVED.
Select one:
True
False - Answer✔false.
LARGER commercial aggregate plants are the major source of crushed stone for the
construction industry in the metropolitan areas.
Properly vibrated concrete is a lower-quality concrete, in terms of strength, reinforcement
protection, resistance to aggressive agents, and overall appearance.
Select one:
True
False - Answer✔false.
higher quality
Increasing roller speed increases compactive effort.
Select one:
True
False - Answer✔false.
Increasing roller speed REDUCES compactive effort.
The pavement performance would not suffer if asphalt concrete is made from a segregated
stockpile.
Select one:
True
False - Answer✔false.
The pavement performance would WOULD suffer if asphalt concrete is made from a segregated
stockpile.
A batch plant mixes 15 tons of asphalt mix with an average mixing cycle of 2.5 min. Plant
efficiency is 90%. Estimate plant production in ton/hr. - Answer✔324
2.5 min. x 60 = 150 seconds. 3600 s./150= 24. 24x15 tons= 360. 360 x .90 accuracy =324
3|Page
, ©BRIGHSTARS 2024/2025 ALL RIGHTS RESERVED.
A specification requires a residual application rate of 0.045 gal/sy. The distributor spray bar
coverage is 8 ft. Estimate the gallons of emulsion needed for a 16 ft wide 1,200 ft stretch of
paving.
Select one:
a. 96 gallons
b. 45 gallons
c. 50 gallons
d. 33 gallons - Answer✔96 gallons
A= 16x1200= 19200
.045/9= .005
19200x.005= 96
A concrete batch plant has a batching chamber capacity of 11 cy and an average batching cycle
time of 2 min. Plant efficiency is 80%. What is the estimated batching production in cy/hr? -
Answer✔264.
60/2=30
30*11=330
330*.80=264
A mechanical pickup device that travels ahead of an asphalt paver and lifts windrowed asphalt
mix material into the hopper of a paver. This allows for continuous paver operation. Windrow
elevators are usually attached to the paver.
Select one:
a. Intake Hopper
b. Flights
c. Hot elevator
d. Windrow elevator - Answer✔windrow elevator
In this test, an asphalt sample at a temperature of 77°F, is subjected to a needle load, with a 100-
g mass and a test time of 5 sec.
Select one:
a. Job Mix Formula (JMF)
b. Revibration
4|Page
