Graphic Scale - ✔✔Included on drawings that will be resized in uneven increments or that might be used
when a person does not have a scale
Architects Scale - ✔✔Uses fractions of an inch to represent feet & inches (1/4", 1/2")
Metric Scale - ✔✔Uses graduated proportions, based on millimeters (1:50, 1:100)
1/4", 1/8", 1/16" - ✔✔3 Common scales for floor plans
Common scale for details - ✔✔3"
3/32", 3/16" (too close to 1/8" and 1/4") - ✔✔Never use what 2 scales
Orthographic, Axonometric, Oblique, Perspective - ✔✔4 Types of presentation drawings
Orthographic Drawings - ✔✔When 3D objects are shown in 2D to scale and perpendicular to the picture
plane: Plans, RCPs, Elevations, Sections
Axonometric Drawings - ✔✔All three planes of object are at an angle to picture plane
Oblique Drawings - ✔✔One plane of the object is parallel to the picture plance
Isometric, Dimetric, Trimetric - ✔✔3 Types of Axonometric Drawings
Perspective Drawings - ✔✔Drawing based on the principle of convergence
