FOA CFOT CERTIFICATION V11
FOA CFOT Certification Exam V11 (100%
Solved) Questions With Answers.
A fiber optic inspection microscope can increase the danger of high powered light sources by
focusing the light coming out of a fiber into your eye. True or False? - ✔✔✔ - True
A fiber optic power meter measures absolute power in dBM (dB referenced to 1 mw) and, when
used with a light source, can measure insertion loss expressed in dB. True or False? - ✔✔✔ -
True
When we say 62.5/125 fiber, what does "62.5" mean? - ✔✔✔ - core size, the diameter in
microns
When we say 50/125 fiber, what does "125" mean? - ✔✔✔ - cladding size, the diameter in
microns
OM3 and OM4 multimode fiber with a 50/125 micron core are now a popular option in premises
cabling systems because they _____. - ✔✔✔ - Are "laser optimized" which gives more distance
capability with gigabit networks using laser sources
In-multimode fiber, the attenuation (reduction in optical power) of the fiber is _____ at 850 nm
than at 1300 nm. - ✔✔✔ - Higher
Which of the following represents a singlemode (smaller core size) fiber size? - ✔✔✔ - 9/125
micron
Singlemode fiber has _____ bandwidth than multimode fiber. - ✔✔✔ - greater
©®™ Page 1
, FOA CFOT CERTIFICATION V11
Most plastic optical fibers are _____. - ✔✔✔ - large core step-index
When you strip singlemode or graded index multimode mode glass fiber, you are removing the
____. - ✔✔✔ - Primary buffer coating
The proper method of pulling optical fiber cables is to attach the pull wire or tape to the ____ of
the cable. - ✔✔✔ - Strength members
According to the references, hybrid cables are cables that contain ____. - ✔✔✔ - Both
singelmode and multimode optical fibers
What type of fiber cable design allows for large numbers of fibers with ultra-high density, small
size (diameter) and lower cost? - ✔✔✔ - ribbon
According to the references, composite cables refer to cables that contain ____> - ✔✔✔ - both
optical fibers and copper conductors
Which optical fiber cables must be grounded? - ✔✔✔ - all cables that contain metallic
elements
Fiber optic cable for use inside a building must _______. - ✔✔✔ - Be rated to meet the
requirements of local building and fire codes
Optical fiber cable with a orange colored jacket generally indicates the cable contains _____. -
✔✔✔ - Multimode fiber
©®™ Page 2
