Components of electronic fuel-injection system With Questions And 100% SURE
ANSWERS
Terms in this set (9)
Located in the vehicle's fuel tank; supplies fuel under pressure to the fuel injectors. Fuel
Electric fuel pump
injectors supply fuel into the combustion chamber.
Fuel filter Filters contaminants from the fuel before it reaches the fuel rail
Fuel rail A manifold that supplies fuel under pressure to the inlets of all the engine's fuel injectors
regulates pressure in the fuel rail according to intake manifold vacuum. excess fuel is bled to
Fuel pressure regulator
the fuel return line , where it is sent back to the fuel tank
Sprays fuel into the intake airstream as it recieves electical signals from the powertrain control
Fuel injector module (PCM). The location of the injector will determine the specific type of fuel injection
system being used on the engine.
Intake air filter
engine
Anotherpasses
name through the air filter.
for the vehicle's central computer. Responsible for control of all functions
Powertrain control module
associated with the engine and transmission.
1/3
