NYC DCAS Plant Maintainer (Hospitals)/Tender
Exam 200 Multiple Choice Practice Questions with
Verified Answers and Detailed Rationales for
2026 Certification Success Graded A+
SECTION 1: BOILER OPERATIONS AND STEAM SYSTEMS (Questions 1–50)
Question 1
A high-pressure boiler is operating at steady load, but the water level begins falling faster than
normal. Which condition should be checked first?
A) Fuel-oil temperature only
B) Boiler feedwater supply and feed pump operation
C) Stack temperature only
D) Lubricant viscosity in the burner motor
ANS: B
Rationale: Loss of boiler water can expose heating surfaces and create a serious overheating
hazard. Feedwater supply, pump operation, valves, and related controls should be checked
promptly to prevent dangerous low-water conditions .
Question 2
What is the primary purpose of a boiler safety valve?
A) To regulate combustion air
B) To maintain constant water level
C) To prevent pressure from exceeding the allowable limit
D) To control feedwater temperature
ANS: C
Rationale: The safety valve automatically releases steam when pressure reaches its set point,
protecting the boiler against excessive pressure that could cause catastrophic failure .
Question 3
,In a properly operating steam boiler, the function of the water gauge glass is to:
A) Measure steam temperature
B) Indicate the approximate water level in the boiler
C) Measure burner pressure
D) Control the feedwater pump
ANS: B
Rationale: The gauge glass provides a direct visual indication of boiler water level, which is
essential for safe operation. Operators must regularly verify that the gauge glass is functioning
correctly .
Question 4
A low-water cutoff is primarily intended to:
A) Increase burner capacity
B) Prevent firing when the boiler water level becomes dangerously low
C) Increase steam pressure
D) Control condensate temperature
ANS: B
Rationale: The low-water cutoff protects the boiler from firing under unsafe low-water
conditions. Without this safety device, heating surfaces could overheat and rupture .
Question 5
Before starting a burner after an unsuccessful ignition attempt, the furnace should first be:
A) Pressurized with fuel
B) Filled with steam
C) Properly purged
D) Closed completely to combustion air
ANS: C
Rationale: Purging removes accumulated combustible gases or vapors from the furnace before
ignition, reducing the risk of an explosive ignition .
,Question 6
What is the principal purpose of a burner flame safeguard system?
A) To increase boiler water temperature
B) To detect flame failure and place the burner in a safe condition
C) To lubricate burner bearings
D) To regulate steam pressure mechanically
ANS: B
Rationale: Flame safeguards monitor the presence of an acceptable flame and initiate fuel
shutoff when flame is lost or unsafe ignition conditions exist .
Question 7
In a forced-draft combustion system, the fan primarily supplies:
A) Feedwater
B) Lubricating oil
C) Combustion air
D) Condensate
ANS: C
Rationale: The forced-draft fan supplies air to support combustion. This fan pushes air into the
furnace under pressure, ensuring adequate oxygen for complete combustion .
Question 8
A balanced-draft boiler generally operates with the furnace pressure:
A) Far above atmospheric pressure
B) Slightly below atmospheric pressure
C) Exactly equal to steam pressure
D) At maximum safety-valve pressure
ANS: B
, Rationale: Balanced draft uses forced-draft and induced-draft equipment so furnace pressure is
maintained slightly negative. This prevents hot gases from escaping into the boiler room .
Question 9
What is the primary function of an induced-draft fan?
A) Force feedwater into the boiler
B) Draw combustion gases through the boiler and toward the stack
C) Increase fuel pressure
D) Circulate lubricating oil
ANS: B
Rationale: The induced-draft fan assists in moving flue gases through the furnace and heat-
transfer surfaces toward the exhaust system .
Question 10
Excessive combustion air can result in:
A) Increased stack heat losses
B) Elimination of all heat losses
C) Elimination of the need for a burner
D) Increased boiler water level
ANS: A
Rationale: Excess air carries additional heated gases through the boiler and can increase stack
losses, reducing combustion efficiency .
Question 11
What is the primary purpose of a steam pressure gauge on a boiler?
A) To measure water hardness
B) To indicate boiler steam pressure
C) To measure fuel viscosity
D) To determine bearing clearance
