,Suggested Study Guide - Essentials
✅ 1. CPU, ALU, CU, Registers, and Cache Memory
● The Central Processing Unit (CPU), often referred to as the brain of the computer, is a crucial
component responsible for executing instructions from computer programs.
● Key Components:
○ Arithmetic Logic Unit (ALU)
■ Function: Performs arithmetic and logical operations (addition, subtraction,
multiplication, division, AND, OR, NOT, etc.).
■ Importance: Essential for executing mathematical calculations and decision-
making processes.
○ Control Unit (CU)
■ Function: Directs the operation of the processor. It tells the computer's memory,
ALU, and I/O devices how to respond to the instructions that have been sent to
the processor.
■ Importance: Coordinates how data moves around the CPU and controls the flow
of data between the CPU and other components of the computer.
○ Registers
■ Function: Small, fast storage locations within the CPU that hold data and
instructions temporarily.
■ Types: Common registers include -
● Accumulator (ACC): The accumulator is a register that stores the results
of arithmetic and logical operations performed by the CPU's Arithmetic
Logic Unit (ALU). It holds the intermediate results of calculations during
program execution.
● Program Counter (PC): The program counter is a special register that
holds the memory address of the next instruction to be fetched and
executed by the CPU.
● Memory Address Register (MAR): The memory address register is a
register that holds the memory address of the data or instruction being
accessed or manipulated in the computer's memory.
● Memory Data Register (MDR): The memory data register is a register that
temporarily holds the data fetched from or to be written to the
computer's memory.
■ Importance: Provide quick access to frequently used data and instructions,
enhancing processing speed.
○ Cache Memory Levels
■ Function: Provides high-speed data access to the CPU, reducing the time needed
to fetch data from the main memory (RAM).
■ Importance: Larger and faster caches can significantly improve CPU
performance.
■ L1 Cache
● Proximity to CPU: Closest to the CPU cores.
● Speed: Fastest among all cache levels due to its proximity and high-
speed SRAM technology.
, ● Size: Smallest in size, typically ranging from 16KB to 128KB per core.
● Purpose: Primarily stores frequently accessed data and instructions to
reduce latency and improve the CPU's processing speed.
● Structure: Often split into two separate caches: one for instructions (L1i)
and one for data (L1d).
■ L2 Cache
● Proximity to CPU: Sits between the L1 cache and the main memory
(RAM).
● Speed: Slower than L1 but faster than L3 cache and main memory.
● Size: Larger than L1, typically ranging from 256KB to several megabytes
per core.
● Purpose: Acts as an intermediary store between L1 and L3, holding data
and instructions that are less frequently accessed than those in L1 but
more frequently than those in RAM.
● Structure: Can be either unified (storing both data and instructions) or
split, similar to L1.
■ L3 Cache
● Proximity to CPU: Shared among multiple CPU cores within the same
processor.
● Speed: Slower than L2 but faster than main memory.
● Size: Larger than L2, typically ranging from a few megabytes to tens of
megabytes, depending on the CPU architecture.
● Purpose: Provides a larger, shared cache that can store data and
instructions accessible by all cores, reducing the need to fetch from
slower main memory.
● Structure: Typically unified, storing both data and instructions.
✅ 2. Pipelining vs. Multithreading vs. Multitasking
○ Pipelining (CPU function) is a hardware technique to increase the instruction throughput
of a CPU by overlapping instruction execution stages.
■ Stages of Pipelining
● Fetch: Retrieving the instruction from memory.
● Decode: Interpreting the instruction and preparing the necessary control
signals.
● Execute: Performing the operation specified by the instruction (e.g.,
arithmetic or logic operations).
● Memory Access: Reading from or writing to memory, if required by the
instruction.
● Write Back: Writing the result back to the register file.
○ Multithreading (Application function) involves executing multiple threads within a single
process concurrently, improving CPU utilization and performance for multithreaded
applications.
■ Thread: A thread is the smallest unit of execution within a process. A process
can contain multiple threads, each running independently but sharing the same
resources, such as memory and file handles.
