, mainstream interface for modern adapter cards. Peripheral Component Interconnect Express (PCIe) bus
x16 x8 x4 x1 slots
a legacy bus type, having been superseded by PCI Express. Peripheral Component Interconnect (PCI)
the standard form factor for most desktop PC motherboards Advanced Technology Extended (ATX)
and cases. 12 inches wide by 9.6 inches deep. Can contain up
to seven expansion slots
standard specifies a 9.6-inch (244 mm x 244 mm) square Micro-ATX (mATX)
board. Can have a maximum of four expansion slots.
6.7 inches (170 mm x 170 mm) square with one expansion slot. Mini-ITX
How many pins is the P1 main motherboard? The main P1 motherboard power connector is a distinctive 2-pin x 12-pin block with
square pin receptacles.
How many pins are fan connectors? Fan connectors are 3- or 4-pin Molex KK format.
This cable can support both analog and digital output Digital Visual Interface (DVI)
This 15-pin port was the standard analog video interface for Video Graphics Array (VGA)
PC devices for a very long time.
Wide SCSI bus has unique IDs from... Each device on a wide SCSI bus must be configured with a unique ID, from 0 to 15. The
host adapter is usually set to 7 or 15.
Integrated drive electronics (IDE) color coded connectors... The blue connector is for the motherboard port. The black (end) and grey (middle)
connectors attach to devices 0 and 1. On the cable, pin 1 is identified with a red stripe.
Serial port is referred to as a... Communications (COM) port.
USB 3.2 Gen 1 speed... 5 Gbps
USB 3.2 Gen 2x1 10 Gbps
