NCCER
Ironworker Questions & Answers | Latest Study
Guide 2026
RESOURCE FEATURES
• NCCER Ironworker practice questions
• Answers for self-assessment
• Detailed explanations and rationales
• Trade-math practice
• Rigging and crane concepts
• Safety-focused review
• Structural-steel practice
• Welding and fabrication review
• Journey-level assessment preparation
, Ironworker NCCER Questions & Answers |
Latest Study Guide 2026
1. Assuming a grip distance of 1", what is the minimum length of the
bolt required for a 3/4" diameter bolt?
• A) 2 1/4" ✓
• B) 2 1/2"
• C) 2"
• D) 3"
Correct Answer: A) 2 1/4"
Rationale: Bolt length = grip (the thickness of material being clamped) +
allowance for threads, nut, and washers. For a 3/4" bolt, the standard
allowance is approximately 1-1/4" (including nut thickness and thread
run-off). 1" (grip) + 1-1/4" = 2-1/4", which is the minimum standard length
available.
2. The location of bridging depends on the length of the:
• A) Beam
• B) Span ✓
• C) Column
• D) Deck
Correct Answer: B) Span
Rationale: Bridging (cross-bracing between joists or beams) is placed at
,intervals along the span to prevent lateral buckling. The maximum spacing
of bridging is dictated by the span length and the joist/beam
manufacturer’s specifications.
3. Before bundles of deck can be landed on a bar joist, what action
must be completed?
• A) Joist must be painted
• B) Joist must have bridging installed ✓
• C) Joist must be welded
• D) Joist must be inspected
Correct Answer: B) Joist must have bridging installed
Rationale: Bar joists are relatively slender and unstable until fully braced.
Bridging provides the necessary lateral stability to support the eccentric
and concentrated loads imposed by landing heavy bundles of metal
decking.
4. When materials are being hoisted to an upper level, a tag line is
used to:
• A) Secure the load to the crane
• B) Help control the load ✓
• C) Measure the load weight
• D) Signal the crane operator
Correct Answer: B) Help control the load
Rationale: A tag line is a rope attached to the load to allow ground
, personnel to guide and prevent rotation or swinging of the load, especially
in windy conditions, without approaching the suspended load.
5. Items such as field welding instructions, hangers, and connection
details are generally found on:
• A) The shop drawings
• B) The detail drawings ✓
• C) The framing plans
• D) The foundation plans
Correct Answer: B) The detail drawings
Rationale: Detail drawings (or connection details) are the specific sheets
that illustrate exact connection methods, bolt sizes, weld symbols, hanger
locations, and field installation notes. Framing plans show layout, but not
the specific connection information.
6. The ability of a structural steel component to resist pulling forces is
known as:
• A) Compressive strength
• B) Tensile strength ✓
• C) Shear strength
• D) Torsional strength
Correct Answer: B) Tensile strength
Rationale: Tension is a pulling or stretching force. Tensile strength is the
maximum stress a material can withstand while being stretched or pulled
