cwb welding inspector exam actual
questions and answers with complete
solutions verified latest update
2026/2027
Don't know?
Terms in this set (133)
faying surface the mating surface of a member that is in
contact with or in close proximity to another
member to which it is to be joined.
joint the junction of the workpieces that are to be
joined
supplementary welding ____are used to provide complementary
symbols information to the basic elements of a
basic welding symbol
weld symbol a symbol that designates each type of weld, it
is drawn in contact with the reference line
and graphically represents the the type of
, weld to be made
left side the vertical line of a weld symbol must always
be on the________________________in the weld
symbol
arrow side a weld symbol placed below the reference
line of a welding symbol is the be made on the
___ ___
plate to be bevelled for bevel and groove welds, if an arrow has a
break then the arrow is pointing toward the
____
closest in a welding symbol with multiple reference
line the sequence of operations start with
the line__to the the arrow
to be removed if an R printed in the rectangle of a backing
bar designation for a welding symbol, the
backing bar is after welding
consumable insert a____is a piece of filler metal placed at the root
of a weld that is completely
fused into the root of the joint
square the symbol for a consumable insert in a welding
symbol is a_______________________placed on
the
opposite side of the reference line from the
weld
Gouge to sound metal GTSM in the tail of awelding symbol means ____
