,How is the auto-throttle (AT) armed while on the ground? AT Button pressed on the Guidance Panel
What is the difference between the Pedestal PA button and Both are correct
the ACP PA button? - Pedestal is active/hot mic only when pressed
- ACP button is active/hot mic after being selected and must be deselected to
change the connection to inactive/cold mic
How many PBE's are provided in the E175 cockpit? 1
What are the brake temperature indications? Green: normal
Amber: caution
Amber dashed: invalid
What happens if a PFD fails? The PFD information should automatically revert to respective side MFD
What is the priority for the Trim System? Back-up
CA
FO
Autopilot
The Emergency Lights Power Units provide electrical 10
energy to power the internal Emergency Lighting system
for _______ minutes.
Which of the following can provide DC power to the All are correct
aircraft? - 2 NiCad batteries
- 3 Transformer Rectifier Units (TRU)
- DC GPU
What controls the engine? A two-channel FADEC
When does the de-clutter of EICAS activate? 30 sec after Land gear retracted, flap slat retracted and all other parameters are
normal
What alerts are generated during a Windshear Caution or Both are Correct
Windshear Warning? - Caution:
i. Amber WSHR on the PFD
ii. Aural “CAUTION WINDSHEAR”
- Warning:
i. Red WSHR on the PFD
ii. Aural “WINDSHEAR, WINDSHEAR, WINDSHEAR”
How may the COMMs be tuned? Both are Correct
- Either MCDU via the RADIO Page
- Respective Sides CCD/PFD
i. CA’s Side = COMM/NAV 1
ii. FO’s Side = COMM/NAV 2
If the Primary and Secondary radio functions are not Via the Backup Tuning function on MCDU 2
available, how would you tune the COMMs, NAVs and
Transponder?
,How can the low-rate bottle be discharged if the airplane is The extinguishing button must be pressed again
on the ground?
We know the dashed lead in markings approaching a 104 feet
runway is 150'. If I am exiting a runway and stopped at the
beginning of these markings (which is 150' from the
runway), I know I am clear of the runway because my
plane is only ______ long.
The EGPWS database consists of all hard surface 3500
runways that are greater than ____ feet in length.
Which statement(s) is true regarding the Fire test? All are correct
- The fire warning light on ITT indicators illuminate.
- The fire aural warning sounds.
- The fire extinguisher handles illuminate steady.
What does DES NOW do? Allows aircraft to descend early at 1000fpm till PTH intercept
What is the Purpose of the Pre-cooler? Cools the bleed air coming from the engine to the AMS
When is the electrical and pneumatic loading available 95% RPM plus 3 seconds
during APU start?
What Fuel Pumps are capable of providing fuel to the All are Correct
APU? - Batteries 'ON' only = DC Fuel Pump in Right Tank
- AC powered airplane = ACMP 2
- Right engine running = RH Ejector Fuel Pump
During preflight, how would you know if the cockpit crew The green blowout disc would be missing on the forward right side of the fuselage.
oxygen had been over
pressurized?
What controls ATTCS? Engine FADEC
What are the different modes of the cockpit quick donning All are correct
O2 mask? - Emergency Setting - Pure oxygen with positive pressure.
- 100% Setting - Pure oxygen at all altitudes.
- Normal Setting - Oxygen/Air mixture
How many smoke detectors are installed in the cargo 3 in the FWD
compartments? 2 in the AFT
What does a "CAS MSG" mean on the PFD(s)? All are correct
- Indicates that the CAS lists from the 2 Monitor Warning Function computers do not
match
i. If the 2 CAS messages are continuously different for 20 sec a mis-compare
indication is shown
ii. Can change source via MCDU Setup Page
What is the purpose of the Ramp Horn buttons installed in To call Ground Personnel via a continuous horn sound when pressed
the cockpit?
, What happens after 3 overspeed detection events? FADEC will not re-light the engine
Will the Speed brakes / Ground spoilers function in No, but Roll Spoiler function is still available via default programmed values
'DIRECT' mode?
How do you select auto-tune if not already selected? All are correct
- Must be in FMS mode
- Preview must be off
- Double select standby NAV freq and set or delete FREQ ID on Prog Page
How is a "bad" DVDR test alerted? a CVR AFT (FWD) FAIL advisory message on the EICAS
when the button is pressed
On the ground, when will ACMP 1 or 2 automatically All are correct
activate with both engines running? - TL set to T/O
- Wheel-speed greater than 50kt
- Flaps greater than 0
What pump is used once an engine is started? Primary ejector pump
Which hydraulic system(s) control the Nosewheel HYD 2
steering?
What is external pneumatic air used for? Both are correct
- Engine start on the ground
- ECS on the ground
How is BATT 2 configured during an APU start? Both are correct
- BATT 2 is isolated from the system
- BATT 2 is tied directly to the APU start bus to power the APU starter
If one of the AOA limiting sensors fail in flight, will the Stall No
Protection system still be capable of performing AOA
limiting?
Are fault(s) in the water system monitored from the No
cockpit?
What does the EICAS FULL button do? Turns off the de-clutter mode
When does the VTA Appear? One minute prior to TOD
What is the primary purpose of HYD 3 system? Back up for the flight controls
When S.E. taxiing (ENG1 or 2) and the APU running, Yes, there would be normal windshield heating since you have two sources of AC
would both windshields be heated? power
