1. Using spherical coordinates, find the capacitance formed by two concentric spherical
conducting shells of radius a, and b. What is the capacitance of a metallic marble with a
diameter of 1cm in free space? Hint: let 𝑏 → ∞, thus, 𝐶 = 4𝜋𝜀𝜀0𝑎 = 0.55𝑝𝐹.
Solution: Suppose the inner sphere has a surface charge density of +𝜌𝑆. The outer surface
charge density is negative, and proportionally smaller (by (𝑎/𝑏)2) to keep the total charge
the same.
-
+
+S - + a + -
b
+
-
From Gauss’s law:
ф𝐷 ⋅ 𝑑𝑆 = 𝑄𝑄 = +𝜌𝑆4𝜋𝑎2
𝑆
Thus, inside the sphere (𝑎 ≤ 𝑟 ≤ 𝑏):
𝑎2
𝐷 = 𝜌𝑆
𝑎𝑟
𝑟2
Assuming a potential of 𝑉0 between the inner and outer surfaces, we have:
𝑎 2 1 1
𝑉0 = − � 1 𝜌𝑆 𝑎 𝑑𝑟 = 𝜌𝑆 𝑎2( − )
𝑏 𝜖 𝑟2 𝜖 𝑎 𝑏
Thus:
𝑄𝑄 𝜌𝑆4𝜋𝑎2 4𝜋𝜖
𝐶=𝑉 = =
𝜌𝑆 1 1 1 1
𝑎−𝑏
0
𝜖 𝑎 (𝑎 − 𝑏)
2
1
In the case of a metallic marble, 𝑏 → ∞, and hence: 𝐶 = 4𝜋𝜀𝜀0 𝑎. Letting 𝜀𝜀0 = ×
36𝜋
10−9, and 𝑎 = 0.5𝑐𝑚, it yields 𝐶 = 5 𝑝𝐹 = 0.55𝑝𝐹.
9
3
, 2. Consider the parallel plate capacitor containing two different dielectrics. Find the total
capacitance as a function of the parameters shown in the figure.
Area: A
1
d1
2
d2
Solution: Since in the boundary no charge exists (perfect insulator), the normal component
of the electric flux density has to be equal in each dielectric. That is:
𝐷1 = 𝐷𝟐𝟐
Accordingly:
𝜖1𝐸1 = 𝜖2𝐸𝟐𝟐
Assuming a surface charge density of +𝜌𝑆 for the top plate, and −𝜌𝑆 for the bottom plate, the
electric field (or flux has a component only in z direction, and we have:
𝐷1 = 𝐷𝟐𝟐 = −𝜌𝑆𝑎𝑧
If the potential between the top ad bottom plates is 𝑉0, based on the line integral we obtain:
𝑑1+𝑑2 𝑑2
−𝜌𝑆 𝑑1+𝑑2 −𝜌
𝑆 𝜌𝑆 𝜌𝑆
𝑉0 = − � 𝐸. 𝑑𝑧 = − � 𝜖 𝑑𝑧 − � 𝜖 𝑑𝑧 = 𝜖 𝑑1 + 𝜖 𝑑2
0 0 2 𝑑2 1 1 2
Since the total charge on each plate is: 𝑄𝑄 = 𝜌𝑆𝐴, the capacitance is found to be:
𝑄𝑄 𝐴
𝐶=𝑉 = 𝑑 𝑑
4
