Semester 1 Y3 Final IEC Exam Questions and Answers
Semester 1 Y3 Final IEC Exam Questions
and Answers
"as-built" - answer✔-According to the BCES specs, a set of drawings is to be
maintained at the jobsite for the purpose of recording the final size, location and
interrelation of work as the job progresses. This set of __ drawings is used to
indicate the location of equipment, including concealed conduit and equipment.
specific to a particular project - answer✔-Written specifications are __.
innerduct - answer✔-BCES specs require that all fiber optic backbone cable shall
be installed in __.
more information about some aspect of the project - answer✔-On a construction
project, an RFI is used to obtain __.
electricial contractor - answer✔-According to the BCES specs, damage repairs to
the factory painted finish of electrical equipment is the responsibility of the __.
The architect provides written approval - answer✔-You can deviate from the specs
if __.
installed in conduit - answer✔-The BCES spec require cafeteria sound system
cable installed above sheetrock ceiling to be __.
6 - answer✔-The BCES Specs require that convenience receptacles be installed at
a height of __ inches above counter tops or back splashes.
Semester 1 Y3 Final IEC Exam Questions and Answers
, Semester 1 Y3 Final IEC Exam Questions and Answers
the project manager - answer✔-On a construction project, PM is the designation
for ___.
electrical - answer✔-Prior to construction, the __ electrical contractor is
responsible for verifying that conductors have sufficient ampacity to serve
equipment furnished by the MC.
8'-0" - answer✔-The concrete contractor will build the BCES light pole bases so
that the bottom of the concrete is at a depth of __ below the top of grade or paving.
44' 7 3/4" - answer✔-You are going to set a 1900 box north of column line F.5 on
the bottom of the 1st bar joist east of the beam on column line 11. Then you are
going to run EMT due east on the bottom of the bar joists and hit joists that are
installed as shown and the 1900 boxes are centered under the bar joists, you should
need __ of EMT to run between the two boxes in a straight line.
120.00 - answer✔-Adjacent to the BCES property, the width of the right-of-way
across FM Hwy 646 is __ feet.
1" = 50' - answer✔-The scale used on the BCES utility plan is __.
30 - answer✔-Re: S1.2. A typical section is cut through the exterior wall. See
1/S4.1. Conduit will be run underground out to the site lighting. It will originate
within the building. It will be routed between the piers. The top of the conduit must
be at least __ below the finished floor to pass under the grade beams.
16 - answer✔-The height of the beam along column line F.5 that spans between
columns 11 & 12.9 is __".
