, C 39 ROOFING TRADE TEST 1 AND TEST 2
EXAM with Questions and Answers/Plus a
Rationale Updated 2026 A+/Instant Download
PDF
EXAM COVERAGE - 1. Roofing Materials and Properties - 2.
Structural Framing and Truss Design - 3. Waterproofing and
Underlayment Systems - 4. Flashing Installation and Details - 5.
Drainage and Gutter Systems - 6. Ventilation and Thermal
Insulation - 7. Safety Regulations and OSHA Standards - 8.
Estimating and Blueprint Reading - 9. Tool Maintenance and
Operation - 10. Building Codes and Inspection Standards
1. When installing a concrete interlocking tile roof on a low-sloping timber roof structure with a
pitch of 15 degrees, which of the following preparatory steps is strictly required by standard
roofing trade practices to prevent wind-driven rain ingress?
A. Applying a single layer of standard 15lb organic felt horizontally from eave to ridge
B. Installing a high-performance self-adhering modified bitumen underlayment across the
entire deck
C. Reducing the batten spacing by 50 percent to increase structural fastening capacity
D. Applying a continuous bead of polyurethane sealant along every interlocking side lap
Answer: B [Correct Answer]
Rationale: For low-pitched roofs near or below the standard threshold for tiles (typically 20
degrees), wind-driven rain can easily bypass the laps, making a fully adhered waterproof
underlayment membrane mandatory. Option A provides inadequate protection for low slopes,
option C incorrectly alters batten dimensions instead of addressing deck waterproofing, and
option D would disrupt the drainage channels and thermal expansion of the interlocking tiles.
,2. A roofing artisan is evaluating a timber hip roof frame before laying clay pantiles. The hip rafters
appear to be sagging slightly under a heavy localized dead load. Which corrective intervention is
most structurally sound according to standard trade framing principles?
A. Bolting flat steel flitch plates directly to the exterior faces of the hip rafters to increase shear
resistance
B. Installing intermediate timber struts and support braces tied back to sturdy internal
load-bearing walls
C. Notching the top edge of the hip rafter to recess a heavy-gauge structural channel beam
D. Doubling the roof batten thickness directly above the sagging area to level out the exterior tile
plane
Answer: B [Correct Answer]
Rationale: Supporting sagging structural framing members requires transferring the eccentric
loads down to stable load-bearing walls using proper struts or braces. Option A addresses shear
rather than deflection/sagging directly, option C severely compromises the structural integrity of
the hip rafter by cutting into its core, and option D merely masks the surface defect without
resolving the underlying structural failure.
3. During the installation of a standing seam metal roof system made of copper, a technician must
account for thermal movement. What is the primary reason copper requires careful allowance for
linear expansion compared to galvanized steel?
A. Copper has a significantly lower tensile yield strength than galvanized steel
B. Copper possesses a higher coefficient of thermal expansion combined with a lower
modulus of elasticity
C. Copper reacts electrochemically with standard atmospheric moisture much faster than steel
D. Copper panels are manufactured in much longer continuous lengths than rolled steel sheets
Answer: B [Correct Answer]
Rationale: Copper expands and contracts significantly more with temperature fluctuations than
steel, and its mechanical properties mean it exerts high stress on fixed points if movement is
restrained. Option A is unrelated to thermal expansion behavior, option C refers to corrosion
rates rather than thermal properties, and option D is incorrect since metal panels are cut to
specification regardless of material.
, 4. When designing a concealed valley detail for a heavy slate roofing project, what is the minimum
recommended width of the metal valley trough to prevent water overflow during intense
downpours?
A. 100 millimeters
B. 150 millimeters
C. 450 millimeters
D. 900 millimeters
Answer: C [Correct Answer]
Rationale: Standard architectural sheet metal guidelines specify that concealed or open valleys
on slate and tile roofs should be at least 450mm (18 inches) wide to accommodate high-volume
water runoff and splashing. Options A and B are far too narrow and invite overflow into the
building interior, while option D is excessively wide, uneconomical, and structurally impractical
for standard valley boards.
5. A trade professional is troubleshooting persistent leaks in a chimney cricket (saddle) installed on
a steep shingle roof. Water is penetrating the upper apex of the cricket. What is the most likely
installation error that caused this failure?
A. The cricket pitch was built at a slope steeper than the main roof pitch
B. The flashing step pieces were integrated without proper headlap or counter-flashing
reglets cut into the masonry
C. The underlying plywood deck of the cricket was constructed using exterior-grade plywood
instead of OSB
D. The roofing nails used to anchor the cricket flashing penetrated the vertical mortar joints
instead of bricks
Answer: B [Correct Answer]
Rationale: Chimney crickets require meticulous step flashing and counter-flashing embedded
into mortar reglets with sufficient headlap to prevent water from cascading behind the metal
joints. Option A would actually improve drainage away from the chimney, option C has no
impact on water ingress if flashing is correct, and option D does not directly explain a leak at
the apex unless waterproofing integration was missed.
