Terms in this set (54)
1. What type of drawing would you look at to find the B. Instrument location drawing
instrument on the project?
A. Instrument specification sheet drawing
B. Instrument location drawing
C. Instrument index
D. Instrumentation detail drawing
2. What kind of drawing would you look at to find the D. Instrumentation location drawing
height of the instrument to be installed?
A. P&id drawing
B. Electrical drawing
C. Ask the operator
D. Instrumentation location drawing
3. A control loop is a combination of two or more True
institutions control functions arranged so that signals
pass from one to another for the purpose of
measurement, and/ control of a process variable?
True or False
, 4. On a instrument it has a TAG on it, first letter is P, what D. Pressure
does it represent?
A. Level
B. Temperature
C. Flow rate
D. Pressure
5. On an instrument it has a TAG on it, first letter is F, B. Flow rate
what does it represent?
A. Temperature
B. Flow rate
C. Level
D. Pressure
6. On a instrument it has a TAG on it, first letter is T, what A. Temperature
does it represent?
A. Temperature
B. Flow rate
C. Level
D. Pressure
7. Who established a standard set symbol, and B. ISA
identification techniques that are widely used for
instrument drawings, and documents?
A. OSHA
B. ISA
C. NEC
D. SAE
8. A hexagon symbol is used flit represent a ________? B. Computer function
A. Shared control device
B. Computer function
C. Discrete instrument
D. Programmable logic control
9. An instrument signal line that consists of a single solid B. Hydraulic signal
line with "L's" drawn through represents?
A. Pneumatic signal
B. Hydraulic signal
C. Lighting protection circuit
D. Process connection
10. The signal line symbols that have groups of the C. Electrical or electronic lines
slashes across the main line represent ______?
A. Process lines
B. Pneumatic lines
C. Electrical or electronic lines
D. Hydraulic lines
11. An instrument location drawing typically shows the B. Plan view of the area
general location of the instrument in reference of the
_____?
A. Loop sheet
B. Plan view of the area
C. Power distribution center
D. Computer system
