MN DENTAL JURISPRUDENCE
COMPREHENSIVE STUDY GUIDE 2026
FULL QUESTIONS AND SOLUTIONS
GRADED A+
◍ the above symbol is a.
Answer: variable or needle valve
◍ a DCV with 2 flow path and 3 fluid ports is.
Answer: 3port 2 position dcv
◍ Which type of pneumatic motor would be for a hoist.
Answer: piston
◍ The function of a pressure regulator is to.
Answer: maintain a constant pressure.
◍ Main Scale.
Answer: Identify Part No. 1
◍ In a pneumatic circuit Q=20l/min pressure drop at 1 bar.
Answer: Q=15
◍ needle valves are used to.
Answer: adjust flow rate in both directions
◍ pneumatics cylinders are actuators that convert the energy of a pressurized
fluid into.
Answer: linear motion
◍ Locking Screws.
Answer: Identfiify Part No. 2 and 3
, ◍ When the actuator does not work against a constant load.
Answer: both are commonly used to control speed
◍ a needle valve consists of a valve containing.
Answer: 2 ports a needle and seat and a threaded needle stem
◍ Frame.
Answer: Identify Part No. 4
◍ Fixed Jaw.
Answer: Identify Part No. 5
◍ Sliding Jaw.
Answer: Identify Part No. 6
◍ pneumatic actuators are used to convert.
Answer: the energy stored in a pressurized fluid into motion
◍ Vernier Scale.
Answer: Identify Part No. 7
◍ the housing and spools of pilot operated valves.
Answer: are similar to those of a direct
◍ the function of a needle valve is to provide a ______ flow in a pneumatic
system.
Answer: adjustable
◍ Horizontal Adjustment Screw.
Answer: Identify Part No. 8
◍ the above symbol is a.
Answer: Muffler
◍ in a 3port 2 position DCV how many flow paths are there.
Answer: 2
◍ what could be the purpose of an accumulator in a pneumatic system.
Answer: mitigate the effects of long tubing
