,40 Biopotential Measurements and Electrodes
7 Solutions
1. Block diagram for a cochlear implant
Tx Coil
Power
Recovery
Transmitter
Audio DSP + N-channel
ADC Cochlea
AFE Filter Bank Neuro-
stimulator
Microphone Data Flexible
Demodulato r Electrode
Battery and External Power Management Arraỵ
Rx Coil
Skin
(a) Microphone: transduces audio signals to electrical impulses.
(b) Audio AFE: a set of amplifiers that take the small amplitude microphone signal
and amplifỵ it to the full range of ADC filtering signals outside audio range.
(c) ADC: digitizes signals
(d) DSP: Further filtering in digital domain plus channelization to determine which
cochlear electrode to stimulate.
(e) Transmitter: Power amplifier for the appropriate frequencỵ and supplỵ
required to drive the external coil.
(f) Tx and Rx coils: provide inductive coupling for power and data trans-
mission.
(g) Power Recoverỵ: Rectifier and Regulators, doing AC/DC power conver- sion.
(h) Data demodulator: recover the data signals in the transmitted carrier wave.
Amplifiers and Comparator or ADC.
(i) N-channel Neurostimulator: N-programmable pulse current sources to
stimulate hair cells on the cochlea.
(j) Flexible Electrode arraỵ: insertable into the cochlea reaching areas of hair
cells corresponding to different frequencies.
, Biopotential Measurements and Electrodes 41
