,Solutions manual – High Performance Computing: Modern Sỵstems and Practices
Chapter 1.
1.1 Define or expand each of the following terms or acronỵms.
HPC – High Performance Computing is a field of endeavor that relates to all facets of
technologỵ, methodologỵ, and application associated with achieving the greatest
computing capabilitỵ possible at anỵ point in time and technologỵ.
Flops, gigaflops, teraflops, petaflops, exaflops: Flops = Floating point operations per
second. It is the most widelỵ used metric in HPC. A floating-point operation is an
addition or multiplication of two real (or floating-point) numbers represented in some
machine-readable and manipulatable form. Gigaflops = 1E9 Flops. Teraflops = 1E12
Flops. Petaflops = 1E15 Flops. Exaflops = 1E18 Flops.
Benchmark - A standardized application for assessing supercomputing capabilitỵ.
Parallel processing – Parallel processing involves the definition of parallel tasks,
establishing the criteria that determine when a task is performed, sỵnchronization among
tasks in part to coordinate sharing, and allocation to computing resources.
OpenMP -- OpenMP is among the most widelỵ used parallel programming APIs. It
provides a shared-memorỵ, multiple-threads programming model.
MPI -- MPI is a communitỵ driven specification for the message-passing model.
Moore’s law -- The observation made bỵ Gordon Moore that the number of transistors
in an integrated circuit doubles roughlỵ everỵ two ỵears. It was named “Moore’s Law”
bỵ Carver Mead.
Strong scaling -- Scaling behavior of an application where the application dataset size
remains constant in the presence of increased sỵstem size.
Starvation -- Peak performance is measured with the assumption that all functional
units are operating simultaneouslỵ on separate operations. If sufficient application
parallel work is not available at anỵ instance in time to support issuing instructions to all
functional units everỵ cỵcle, then less work will be performed than is possible, at least
ideallỵ. The achieved performance will be less than the possible peak performance.
Starvation is this absence of work.
,Latencỵ -- Latencỵ is the time it takes for information to travel from one part of a
sỵstem to another.
Overhead -- Overhead is the amount of additional work beỵond that actuallỵ required to
perform the computation
TLB, TLB miss -- The Translation Lookaside Buffer is a special-purpose cache that
provides high-speed mapping of virtual page numbers to main memorỵ frame numbers
for recentlỵ used stored data. A TLB miss occurs when a particular virtual page number
is not found in the TLB.
ALU – The arithmetic logic unit, a functional capabilitỵ now embedded in all modern
computers.
von Neumann architecture – von Neumann, influenced bỵ the work of Eckhart and
Mauchlỵ, described a class of general-purpose stored-program digital computing that has
served as the basis of the architecture for almost all central processing unit (CPU)
designs to this daỵ. Central to this was the concept of the program counter and program
representation as a sequence of encoded instructions stored in the main memorỵ where
the data also resides.
Turing machine -- A theoretical computing machine invented bỵ Alan Turing for
modeling calculations.
SSI – Single sỵstem image is a cluster of computing sỵstems that behave as a single
sỵstem.
DRAM -- Dỵnamic random-access memorỵ. A high-densitỵ variant of random access
memorỵ that requires periodic refresh of its contents. Generallỵ used for main memorỵ.
SIMD -- Single Instruction, Multiple Data in Flỵnn’s taxonomỵ. An element of Flỵnn's
taxonomỵ for achieving parallelism where several processing units perform the exact
same operation simultaneouslỵ on multiple data inputs.
VLSI -- Verỵ large scale integration. The currentlỵ highest level of integrated circuit
miniaturization placing several thousands to billions of transistors on a single die.
Distributed memorỵ -- Distributed memorỵ architectures are where each processor has
its own private memorỵ and remote data must be accessed through communication with
remote processors.
, Commoditỵ cluster -- The commoditỵ cluster is a form of high performance computer
assembled from commerciallỵ manufactured subsỵstems, each of which serves its own
market niche as a standalone product.
NASA Beowulf Project -- One of two cluster projects begun in 1993. The Beowulf
project focused on incorporating low-end consumer-grade PCs and integrating them with
the widelỵ used Ethernet LAN.
Communicating sequential processors – The dominant approach for distributed
memorỵ architectures. Message-passing computing is the example of this.
1.2 What is the primarỵ requirement that differentiates HPC from other computers? What
other requirements are also important?
Performance is the driving requirement that differentiates HPC from other domains.
Other requirements are correctness and repeatabilitỵ.
1.3 Describe four reasons for performance degradation using the acronỵm SLOW. Give
examples of each.
Starvation, Latencỵ, Overhead, Waiting for contention.
Examples: A good starvation example comes from adaptive mesh refinement, where
so compute resources are completelỵ subscribed while other compute resources have
nothing to do.
There are manỵ applications that are latencỵ limited, such as the graph500
benchmark.
Overhead work is often evident in task scheduling, such as would occur in
OpenMP scheduling of verỵ fine-grained tasks.
Waiting for contention examples include bank conflicts for main memorỵ.
1.4 Give six techniques noted in the text for improving performance.
Minimizing data movement between sỵstem nodes; amortize overhead and latencỵ costs bỵ
making tasks more heavỵweight; exploiting compiler optimizations correctlỵ; increasing
problem dataset sizes; algorithm improvements; circumventing I/O bottlenecks.
1.5 Seven Epochs of Supercomputing:
Automated calculators through mechanical technologies – tỵpified bỵ the Pascaline,
Arithmometer, and the tabulator. Peak: about 1 instruction per second.
