ADDA Mechanical Drafter Certification LATEST UPDATED 2025/2026 Practice Exam WITH COMPLETE COMPREHENSIVE Questions and SURE VERIFIED SOLUTIONS 100% (MOST FREQUENTLY TESTED) GRADED AT A+ SCORE SURE GUARANTEED PASS!! 1. The top view of an object shows the height and depth dimensions. - ANSWER false 2. In a cavalier oblique pictorial, the depth dimension is drawn halfscale. - ANSWER false 3. A two-point perspective has one vanishing point and one station point. - ANSWER false 4. An auxiliary view may be used to find the true length of a line. - ANSWER true 5. If a surface is perpendicular to a primary plane but not parallel to any of the primary planes, a secondary auxiliary view must be constructed to find its true shape. - ANSWER false 6. The reference plane/fold line must be constructed parallel to the edge view of a surface to construct the true size and shape of the surface. - ANSWER true 7. Hidden lines are usually shown on pictorial drawings. - ANSWER false 8. Finish marks are placed on the surface view of finished surfaces. - ANSWER false 9. If a part is finished all over, it must still have appropriate finish marks on all surfaces. - ANSWER false 10. A depth auxiliary view is projected from the right-side view. - ANSWER false 11. Parallel lines are never in the same plane. - ANSWER false 12. The purpose of an auxiliary view is to show the foreshortened view of a surface. - ANSWER false 13. There are 3600 seconds in a degree (angle measure). - ANSWER true 14. There are 3 standard projection planes: frontal, horizontal, and profile. - ANSWER true 15. In first angle projection, the object is between the viewer and projection plane. - ANSWER true 16. An oblique plane is perpendicular to one of the of the primary planes. - ANSWER false 17. The front view of an object should be chosen to maximize hidden lines. - ANSWER false 18. Extension lines may not cross other extension lines. - ANSWER false 19. The first line of dimensions is usually spaced 3/4" from the view. - ANSWER false 20. Reference dimensions may be used for production purposes. - ANSWER false 21. A trimetric pictorial has 3 different scales and axes. - ANSWER true 22. In an isometric drawing, measurements are taken from the isometric axis at full scale. - ANSWER true 23. Rolled stock, plate, or sheet materials do not require finish marks. - ANSWER true 24. An Engineering Change Notice (ECN) is not required if only the assembly process for components is being revised. - ANSWER false 25. A coiled elastic body designed to store energy when deflected is a spring. - ANSWER true 26. Symbols should precede sizes in dimensioning (i.e R.500, not .500 R). - ANSWER true 27. The sum of the lengths of a triangle's 2 sides must be greater than the 3rd side's length. - ANSWER true
