IMSA TRAFFIC SIGNAL TECHNICIAN
LEVEL 1
Questions and Verified Answers | Grade A | 100% Correct
Update
A comprehensive 100-question certification examination aligned with the International Municipal Signal Association
(IMSA) Traffic Signal Technician Level 1 Certification Standards. This examination has been developed in accordance
with the Manual on Uniform Traffic Control Devices (MUTCD), the National Electrical Code (NEC), NFPA 70E
electrical safety standards, NEMA (National Electrical Manufacturers Association) standards, and the Institute of
Transportation Engineers (ITE) recommended practices.
Each question has been verified for technical accuracy against current industry references. The examination is
structured across six core competency domains and includes a calibrated mix of recall (25%), application (50%), and
analysis (25%) cognitive levels, with 70% scenario-based items and 30% direct-knowledge items. Distractors reflect
common field errors, electrical misconceptions, and timing miscalculations observed in certification candidate
populations.
Section Domain Questions
1 Traffic Signal Fundamentals & Standards 15
2 Electrical Fundamentals & Safety 18
International Municipal Signal Association | IMSA Certification Program
Aligned with MUTCD, NEC, NFPA 70E, NEMA, and ITE Standards
, 3 Traffic Signal Components & Equipment 18
4 Signal Phasing & Timing 15
5 Installation, Maintenance, & Troubleshooting 18
6 Traffic Signal Controllers & Detection 16
TOTAL 100
Instructions: Select the single best answer for each question. Verified correct answers and full rationales appear
beneath each item. Cognitive distribution: 25% recall, 50% application, 25% analysis. Special inclusions: 20
scenario-based troubleshooting items, 15 electrical calculation and safety items, and 10 signal phasing and timing items.
International Municipal Signal Association | IMSA Certification Program
Aligned with MUTCD, NEC, NFPA 70E, NEMA, and ITE Standards
,IMSA Traffic Signal Technician Level 1 | Certification Exam Edition
Section 1: Traffic Signal Fundamentals & Standards
Q1: A city traffic engineer is evaluating whether an intersection should remain unsignalized or
receive a traffic control signal. According to the MUTCD, which of the following is the PRIMARY
purpose of a traffic control signal?
A. To eliminate all vehicle delay at the intersection by alternating right-of-way equally among all approaches.
B. To assign right-of-way to specific traffic movements or traffic streams in a manner that
improves safety and operational efficiency when warranted by engineering study.
*[CORRECT]*
C. To replace all-way stops at every four-leg intersection within an urbanized area regardless of traffic volume.
D. To enforce lower speed limits by displaying a red indication to speeding vehicles detected by radar.
Correct Answer: B
Rationale: The MUTCD (Section 4B.02) states that traffic control signals are justified only when an engineering study shows
that the assignment of right-of-way will produce improved safety and operational efficiency. They are not intended to eliminate
delay (A), to be installed universally (C), or to function as speed-enforcement devices (D).
Q2: A technician is reviewing a signal head installation drawing that references the most current
national standard for traffic control signals. Which publication governs the design, placement,
operation, and maintenance of traffic control signals in the United States?
A. NFPA 70 (National Electrical Code), Article 768 only.
B. NEMA TS 2 standard for controller cabinets.
C. Manual on Uniform Traffic Control Devices (MUTCD). *[CORRECT]*
D. IEEE 1455 controller communication specification.
Correct Answer: C
Rationale: The MUTCD, administered by FHWA, is the national standard for all traffic control devices, including traffic
signals. NFPA 70 Article 768 governs the electrical wiring within signal installations (A), NEMA TS 2 governs controller cabinet
construction (B), and IEEE 1455 is a communications protocol (D), but the MUTCD governs the device itself.
Q3: An intersection is being studied for signalization under MUTCD Warrant 1 (Eight-Hour
Vehicular Volume). Which condition must be met for this warrant to be satisfied?
A. The major-street and minor-street volumes each exceed the prescribed minimum thresholds for any single
hour of the day.
B. The major-street and minor-street volumes each exceed the prescribed minimum
thresholds for each of any eight hours of an average day. *[CORRECT]*
C. The minor-street volume exceeds the major-street volume for eight consecutive hours.
D. The combined total of all-way stop delay exceeds eight vehicle-hours per day.
Correct Answer: B
Rationale: MUTCD Warrant 1 requires that both the major-street and minor-street vehicular volumes each meet or exceed the
specified minimums for each of any eight hours of an average day. A single peak hour falls under Warrant 3 (A), and the
comparison of minor vs major volume (C) and delay-hours (D) are not part of Warrant 1 criteria.
Q4: A rural intersection shows vehicular volumes that do NOT meet Warrant 1 thresholds but DO
exceed the prescribed four-hour minimums on the major and minor streets. Which warrant applies,
and what additional requirement applies under that warrant?
A. Warrant 1, with no additional conditions.
Page 3 | IMSA TS-1 Exam | 100 Questions, Grade A Verified
, IMSA Traffic Signal Technician Level 1 | Certification Exam Edition
B. Warrant 2 (Four-Hour Vehicular Volume); the typical four-hour volume condition must be
met AND the intersection must be on the major route, with consideration of intersection
geometry. *[CORRECT]*
C. Warrant 3 (Peak Hour); the peak-hour condition alone is sufficient with no other requirements.
D. Warrant 7 (Crash Experience); five or more reportable crashes must have occurred.
Correct Answer: B
Rationale: MUTCD Warrant 2 (Four-Hour Vehicular Volume) requires that the prescribed major- and minor-street volume
curves be met for each of any four hours of an average day, and that the intersection lie on the major route. Warrant 1 (A)
requires eight hours; Warrant 3 (C) is for the peak hour; and Warrant 7 (D) requires crash criteria, not volumes.
Q5: An engineer documents peak-hour volume at a location where the major street carries 1,200
vph and the minor street carries 150 vph, with speeds of 35 mph on the major street. To satisfy
Warrant 3 (Peak Hour), the combination must:
A. Meet the curves of Figure 4C-3 OR 4C-4 and have the minor-street volume exceed the
prescribed minimum for any one peak hour of an average day, considering speed factor
where posted speed exceeds 40 mph. *[CORRECT]*
B. Exceed the eight-hour minimums simultaneously.
C. Document five or more correctable crashes within a 12-month period.
D. Show that 60 pedestrian crossings per hour occur during the peak hour.
Correct Answer: A
Rationale: Warrant 3 (Peak Hour) per MUTCD Figure 4C-3 (urban) or 4C-4 (rural) is satisfied when the major- and
minor-street peak-hour volumes intersect above the curve, with an adjusted curve where major-street speed exceeds 40 mph.
Eight-hour minimums apply to Warrant 1 (B); crash counts apply to Warrant 7 (C); pedestrian counts apply to Warrant 4 (D).
Q6: During a study near a school, an engineer counts 60 pedestrians crossing the major street
during the highest crossing hour. Which warrant may be satisfied, and what minimum conditions
apply?
A. Warrant 4 (Pedestrian Volume) - requires 107 or more pedestrians (for speeds <=35 mph)
during any one hour of an average day, plus the lack of a nearby crosswalk offering
comparable safety. *[CORRECT]*
B. Warrant 5 (School Crossing) - applies only when children are present.
C. Warrant 6 (Coordinated Signal System) - applies only when adjacent signals are coordinated.
D. Warrant 8 (Roadway Network) - applies only at the intersection of two highways.
Correct Answer: A
Rationale: MUTCD Warrant 4 (Pedestrian Volume) requires 107 or more pedestrians per hour (or 133 pph where speed > 35
mph) for any one hour of an average day on the highest-volume crossing, plus a lack of adequate alternative crossing. Warrant
5 (B) specifically covers school children; Warrant 6 (C) addresses coordination; and Warrant 8 (D) addresses network
configuration.
Q7: An elementary school requests a signal where children cross a four-lane undivided major
street. To satisfy MUTCD Warrant 5 (School Crossing), the engineering study must show that:
A. The number of adequate gaps in traffic during the period when children are using the
crossing is less than the number of minutes in the same period, and there are a minimum of
20 students crossing during the highest crossing hour. *[CORRECT]*
B. The vehicular volume exceeds the eight-hour warrant minimum.
C. Five or more reportable crashes have occurred involving pedestrians.
D. The major-street speed exceeds 45 mph and there is no marked crosswalk.
