,Section A - Sampling Theorem AND Nyquist RATE
Q1.
A continuous-time sinusoid of 7 kHz is sampled at 10 kHz. What is the apparent (alias)
frequency in the sampled sequence?
A. 3 kHz B. 7 kHz
C. 2 kHz D. 17 kHz
Correct: A - 3 kHz
Rationale:The Nyquist frequency is 5 kHz. The 7 kHz tone lies 2 kHz above Nyquist, so it
folds to 5 2 = 3 kHz. Aliasing maps f to |f k-fs| for integer k, giving 3 kHz.
Why the other answers are wrong:
B. 7 kHz exceeds the Nyquist frequency of 5 kHz and cannot appear directly in the sampled
spectrum.
C. 2 kHz is the fold distance from Nyquist, not the alias frequency itself.
D. 17 kHz is a sum frequency, not a valid alias in the baseband [0, fs/2].
Reference: Oppenheim & Schafer, Discrete-Time Signal Processing, 3rd Ed., Ch. 4
Q2.
An anti-aliasing low-pass filter is placed before an ADC sampling at 48 kHz. To prevent
aliasing of out-of-band noise, the filter's stopband attenuation should begin at which
frequency?
A. 24 kHz B. 48 kHz
C. 96 kHz D. 12 kHz
Correct: A - 24 kHz
Rationale:The Nyquist frequency is fs/2 = 24 kHz. Components above 24 kHz fold into the
baseband, so the anti-aliasing filter must attenuate them before sampling; the stopband
should begin at the Nyquist frequency.
Why the other answers are wrong:
B. 48 kHz is the sampling rate, not the folding boundary.
C. 96 kHz is twice the sampling rate and is irrelevant to the first Nyquist zone.
D. 12 kHz is fs/4; attenuation starting there would unnecessarily limit the usable baseband.
Reference: Sedra & Smith, Microelectronic Circuits, 8th Ed., Ch. 15 (Data Conversion)
