Which type of feature is parallel to the surface being
dimensioned? - Answer: Dimension line
,The three standard views of an object are __________. - Answer:
Top, front, right side
Which type of lines are used to show the counterbored hole in the
part? - Answer: Hidden lines
The number of views in a drawing __________. - Answer: Is the
fewest number that shows all of the features and dimensions
Which of the following steps is NOT used in the glass box method?
- Answer: Rotate object in glass box.
What type of drawing is shown? - Answer: Multiview
The dimensions of raw material supplied by metal suppliers are
described by the __________. - Answer: Stock size
Which of these requires a computer? - Answer: CAD
An isometric drawing is a type of __________. - Answer: Pictorial
drawing
,In the graphic shown, the two circles are __________. - Answer:
Concentric
Dimensions are used to specify the __________ and location of
the features of an object. - Answer: Size
What feature in the figure shown is a Chamfer? - Answer: D
A __________ dimension is described in inches per foot. - Answer:
Shaft taper
What is the order of precedence of lines in a drawing? - Answer:
Object, Hidden, Center
Which of the following is not one of the six rules for dimensioning
an object? - Answer: Dimension hidden lines
Engineers sometimes use a __________ to measure angles on a
drawing. - Answer: Protractor
What dimension is indicated in this graphic? - Answer: Height
, There are 60 minutes of arc in one __________. - Answer: Degree
In manufacturing, a blueprint is also called what? - Answer: A
technical drawing
The distance across the flats of the hex head shown in the part
drawing is __________ inches. - Answer: 2 ¼
The length of the part shown in the drawing is __________ inches.
- Answer: 9 ¾
Which type best describes the line indicated in the graphic? -
Answer: Object Line
Which of the following bolts is a grade 2? - Answer: A
The hole shown in the graphic is a __________ hole. - Answer:
Counterbore
What are the two types of assembly drawings? - Answer:
Exploded and basic
