Terms in this set (78)
What are the three components of a power system, generation - constant voltage and frequency ideally
and what is the most complex? why do we step up transmission - perfect conductor ideally
voltage at substations? distribution - constant resistive ideally
distribution brings most challenges since the real load is constantly
changing
increasing voltage in a transformer decreases current which mitigates i^2r
loss (copper loss)
Power Systems Test 1.pdf Power Systems Test 1.pdf Power Systems Test 1.pdf
,Power Systems Test 1 Power Systems Test 1.pdf Power Systems Test 1.pdf
Power vs. Energy -Power is a rate of instantaneous wattage, delivered at any given
moment(kw)
-Energy is an amount of energy for a certain amount of time time (kwh-one
watt of electrical power, maintained for one hour, equals one watt-hour of
energy. A thousand of these is a kilowatt-hour (kWh), and note that a
thousand watts for one hour, or one watt for a thousand hours, both equal
one kWh.)
-Energy 1 J = 1 Watt for 1 second or Ws.
consumers are charged for their energy!
what are the three north american interconnections?
Power Systems Test 1.pdf Power Systems Test 1.pdf Power Systems Test 1.pdf
, Power Systems Test 1 Power Systems Test 1.pdf Power Systems Test 1.pdf
what is a oneline diagram? In power engineering, a single-line diagram (SLD), also sometimes called
one-line diagram, is a simplified notation for representing a three-phase
power system.[1]
The one-line diagram has its largest application in power flow studies.
Electrical elements such as circuit breakers, transformers, capacitors, bus
bars, and conductors are shown by standardized schematic symbols.[1]
Instead of representing each of three phases with a separate line or
terminal, only one conductor is represented
Power Systems Test 1.pdf Power Systems Test 1.pdf Power Systems Test 1.pdf
