CALIFORNIA JOURNEYMAN ELECTRICIAN EXAM –
QUESTIONS AND ANSWERS | VERIFIED AND WELL
DETAILED ANSWERS | PLUS RATIONALES |
GUARANTEED PASS | LATEST EXAM UPDATE
*Core Domains*
*General Electrical Knowledge*
*Service, Feeders, and Branch Ci
*Grounding and Bonding*
*Conductors and Overcurrent Prote
*Wiring Methods and Materials*
*Motors and Controls*
*Special Occupancies and Equipmen
*California Electrical Code (CEC
*Introduction*
*The California Journeyman Electrician Exam is a r
individuals possess the necessary expertise to perf
within the state. This exam evaluates a candidate'
as amended by the California Electrical Code, focu
protocols, and proper installation techniques. The
format and incorporates complex scenario-based que
, challenges. By emphasizing practical application an
verifies that the examinee can interpret code requ
the highest professional standards in the electrica
SECTION ONE: QUESTIONS 1–100
1. What is the maximum distance that a manual pull
station can be located from the exit doorway?
A. 3 feet
B. 5 feet
C. 10 feet
D. 15 feet
🟢 B. 5 feet
🔴 Explanation: According to fire alarm standards and
accessibility codes, manual fire alarm boxes must be
located within 5 feet of the exit doorway opening to
ensure visibility and immediate access during an
emergency.
, 2. A 240-volt single-phase motor draws 20 amperes.
What is the minimum size copper THWN conductor
required for the branch circuit?
A. 14 AWG
B. 12 AWG
C. 10 AWG
D. 8 AWG
🟢 C. 10 AWG
🔴 Explanation: Branch circuit conductors for a single
motor must be sized at 125% of the motor’s full-load
current (FLC). 20A x 1.25 = 25A. Per NEC Table 310.16,
10 AWG THWN is rated for 30A.
3. Which of the following is the required color for an
insulated grounded conductor (neutral) 6 AWG or
smaller?
A. Green
B. Black
, C. White
D. Red
🟢 C. White
🔴 Explanation: Under the CEC and NEC, grounded
conductors (neutrals) sized 6 AWG or smaller must be
identified by a continuous white or gray outer finish
along their entire length.
4. What is the minimum clear working space depth in
front of electrical equipment operating at 480 volts
to ground where there are exposed live parts on
one side and grounded parts on the other
(Condition 2)?
A. 3 feet
B. 3.5 feet
C. 4 feet
D. 5 feet
🟢 B. 3.5 feet
