Elevator Mechanic Exam Review
with 216 questions with true
answers2025-2026
,A contractor wants to raise the car speed from 100fpm to 125fpm, it currently has a 12"
sheave. What sheave is required? - VERRIFIED ANSWERS✔️✔️--Diam=12" 12/4=3"
25fpm=3" 100fpm + 25fpm= 12"+3"= 15" sheave
A MOV (Metal Oxide Varistor) burns out. You replace it, but cannot read voltage or
resistance. What should you do? - VERRIFIED ANSWERS✔️✔️--Replace it with a
larger MOV
On a Ward-Leonard circuit the break is set, but the motor is trying to slip through the
break. What is the issue? - VERRIFIED ANSWERS✔️✔️--Suicide Circuit
You have an old DC motor and are adding an SCR drive, what do you do to the
interpoles? - VERRIFIED ANSWERS✔️✔️--Leave the interpoles alone. When adding
a SCR drive to the generator, the series loop is removed, as are the 3 resistors.
Everything else remains the same
,A hydro runs up with no load, but will not run with a full load. What is the issue? -
VERRIFIED ANSWERS✔️✔️--The relief valve is set too low
Runby for a 1:1 hits the CWT buffer 4" below the top landing. CWT runby should be set
at 18". How much should the ropes be shortened? - VERRIFIED ANSWERS✔️✔️--
22"
You need to work on a freight door retiring cam, you LOTO the main line but there is still
power on the cam. What circuit is still hot? - VERRIFIED ANSWERS✔️✔️--Door
Operator Disconnect/ Main Line Disconnect
The contractor requests that the vertical center of a Rack and Pinion hoist be moved.
How do you do this? - VERRIFIED ANSWERS✔️✔️--Adjust Tie Downs and Wall Ties
, Working pressure on a Hydro is 400psi. What is the maximum relief valve setting? -
VERRIFIED ANSWERS✔️✔️--400psi x 150%= 600psi
What must be installed on a false car before operation? - VERRIFIED
ANSWERS✔️✔️--Spring Loaded Safeties.
There is slight arcing between the brush and commutator. What action must be taken? -
VERRIFIED ANSWERS✔️✔️--None.
Heavy arcing=Light brush pressure. Heavy bush pressure=mechanical wear
If rigging gear is roped 3:1 and a BEAM CLAMP is used to lift a 6,000lb load. What is
the beam capacity? - VERRIFIED ANSWERS✔️✔️--18,000lbs. Beam capacity is cut
in half with use of clamp, when rigging all blocks, rope, and clamps will be Equal to the
lowest load rating
