0 1 Figure 1 shows the basic input and output pins for a Johnson decade counter with
decoded outputs.
Figure 1
Figure 2 shows the timing diagram for this counter as a sequence of 11 pulses is
applied to the clock input CK. The counter is triggered by the positive edge of
each pulse.
Figure 2
*02*
IB/M/Jun26/7408/3BE
, 3
Do not write
outside the
0 1 . 1 A square wave of frequency f is applied to CK. box
f
State how the counter can be made to produce pulses of frequency at output Q3.
5
[1 mark]
Question 1 continues on the next page
