Pearson Edexcel GCE A-LEVEL In
Physics (6PH04)
Paper 01 Physics on the Move
SUMMER 2024 EXAM
(AUTHENTIC MARKING SCHEME ATTACHED)
Physics
Write your name
here
Surname Other names
Advanced
Pearson
Unit 4: Physics on
Centre
the Move
Number
Candidate
Number
Edexcel
GCE
Wednesday 11 June 2014 – Afternoon Paper Reference
Time: 1 hour 35 minutes 6PH04/
01
You do not need any other materials. Total
Marks
, SECTION A
Answer ALL questions.
For questions 1–10, in Section A, select one answer from A to D and put a cross in the box .
If you change your mind, put a line through the box and then
mark your new answer with a cross .
1 A footballer kicks a football from the penalty spot. A graph of force on the ball against
time is drawn.
The area under the force-time graph represents
A acceleration
B change in kinetic energy
C change in momentum
D displacement
(Total for Question 1 = 1 mark)
2 Select the row of the table which correctly identifies the quantities conserved in an
inelastic collision.
Momentum Kinetic energy Total energy
A conserved conserved conserved
B conserved not conserved conserved
C conserved not conserved not conserved
D not conserved not conserved not conserved
(Total for Question 2 = 1 mark)
3 Which variables are linked in the de Broglie equation?
A frequency and wavelength of a photon
B wavelength and momentum of a moving electron
C energy and frequency of a photon
D work function and threshold frequency of a metal
(Total for Question 3 = 1 mark)
2
*P43120A01024*
,4 A radioactive isotope of aluminium is 13
25
Al
Select the row in the table that correctly identifies a neutral atom of this isotope.
Neutrons Protons Electrons
A 12 13 12
B 13 12 13
C 13 12 12
D 12 13 13
(Total for Question 4 = 1 mark)
5 A coil of 300 turns each of area 1.5 × 10–4 m2 is placed in a magnetic field with its plane
at right angles to the field. The graph shows how the magnetic flux density B of the field
varies with time t.
B/T
0.08
0.06
0.04
0.02
0
0 2 4 6 8 10
t /ms
The e.m.f. induced in the coil during the first 5 ms is
A 5.4 × 10–1 V
B 4.5 × 10–2 V
C 1.8 × 10–3 V
D 5.4 × 10–4 V
(Total for Question 5 = 1 mark)
3
*P43120A0324* Turn
over
, 6 An electron travelling horizontally enters a uniform electric field which acts vertically
downwards as shown in the diagram.
e–
Which of the following statements is incorrect?
A The electron follows a parabolic path.
B The electron accelerates while in the field.
C The electric force on the electron acts downwards.
D The speed of the electron increases.
(Total for Question 6 = 1 mark)
7 A current of 1.50 A flows in a straight wire of length 0.450 m. The wire is placed in a
uniform magnetic field of flux density 2.00 × 10–3 T which acts perpendicular to the wire.
Under these conditions the magnetic force balances the weight of the wire.
Calculate the mass of the wire.
A 1.32 × 10–2 kg
B 1.35 × 10–3 kg
C 1.38 × 10–4 kg
D 1.35 × 10–4 kg
(Total for Question 7 = 1 mark)
4
*P43120A01024*
Physics (6PH04)
Paper 01 Physics on the Move
SUMMER 2024 EXAM
(AUTHENTIC MARKING SCHEME ATTACHED)
Physics
Write your name
here
Surname Other names
Advanced
Pearson
Unit 4: Physics on
Centre
the Move
Number
Candidate
Number
Edexcel
GCE
Wednesday 11 June 2014 – Afternoon Paper Reference
Time: 1 hour 35 minutes 6PH04/
01
You do not need any other materials. Total
Marks
, SECTION A
Answer ALL questions.
For questions 1–10, in Section A, select one answer from A to D and put a cross in the box .
If you change your mind, put a line through the box and then
mark your new answer with a cross .
1 A footballer kicks a football from the penalty spot. A graph of force on the ball against
time is drawn.
The area under the force-time graph represents
A acceleration
B change in kinetic energy
C change in momentum
D displacement
(Total for Question 1 = 1 mark)
2 Select the row of the table which correctly identifies the quantities conserved in an
inelastic collision.
Momentum Kinetic energy Total energy
A conserved conserved conserved
B conserved not conserved conserved
C conserved not conserved not conserved
D not conserved not conserved not conserved
(Total for Question 2 = 1 mark)
3 Which variables are linked in the de Broglie equation?
A frequency and wavelength of a photon
B wavelength and momentum of a moving electron
C energy and frequency of a photon
D work function and threshold frequency of a metal
(Total for Question 3 = 1 mark)
2
*P43120A01024*
,4 A radioactive isotope of aluminium is 13
25
Al
Select the row in the table that correctly identifies a neutral atom of this isotope.
Neutrons Protons Electrons
A 12 13 12
B 13 12 13
C 13 12 12
D 12 13 13
(Total for Question 4 = 1 mark)
5 A coil of 300 turns each of area 1.5 × 10–4 m2 is placed in a magnetic field with its plane
at right angles to the field. The graph shows how the magnetic flux density B of the field
varies with time t.
B/T
0.08
0.06
0.04
0.02
0
0 2 4 6 8 10
t /ms
The e.m.f. induced in the coil during the first 5 ms is
A 5.4 × 10–1 V
B 4.5 × 10–2 V
C 1.8 × 10–3 V
D 5.4 × 10–4 V
(Total for Question 5 = 1 mark)
3
*P43120A0324* Turn
over
, 6 An electron travelling horizontally enters a uniform electric field which acts vertically
downwards as shown in the diagram.
e–
Which of the following statements is incorrect?
A The electron follows a parabolic path.
B The electron accelerates while in the field.
C The electric force on the electron acts downwards.
D The speed of the electron increases.
(Total for Question 6 = 1 mark)
7 A current of 1.50 A flows in a straight wire of length 0.450 m. The wire is placed in a
uniform magnetic field of flux density 2.00 × 10–3 T which acts perpendicular to the wire.
Under these conditions the magnetic force balances the weight of the wire.
Calculate the mass of the wire.
A 1.32 × 10–2 kg
B 1.35 × 10–3 kg
C 1.38 × 10–4 kg
D 1.35 × 10–4 kg
(Total for Question 7 = 1 mark)
4
*P43120A01024*
