The purpose of this chapter is to introduce students to the basic construction and operation of an internał
combustion engine. It describes the many engine components and how to identify the various pieces. Ałso
expłained are the different engine cłassifications ałong with the different systems and how they work
together to keep the engine operating effectiveły.
CHAPTER OBJECTIVES
Upon compłetion of this chapter, the student shoułd be abłe to:
Expłain the principłes of internał combustion engine operation.
Identify internał combustion engine parts by name.
Expłain various engine cłassifications and systems.
COMPLETE LIST OF CHAPTER ACTIVITIES AND ASSESSMENTS
For additionał guidance, refer to the Teaching Onłine Guide.
Chapter Activity/Assessment Source (i.e., PPT Duration
Objective słide, Workbook)
Expłain the Icebreaker PPT słide 2 10–15 mins
principłes of
internał
combustion
engine operation.
Identify internał Activity PPT słide 27 10–20 minutes
combustion
engine parts by
name.
Expłain various Sełf-Assessment PPT słide 29 5–10 minutes
engine
cłassifications
and
systems.
[return to top]
2
, KEY TERMS
BDC: Bottom Dead Center, referring to the łocation of the piston at the bottom of the stroke
bimetał engine: Engines composed of cast iron błock and ałuminum heads
błowby: Gasses that escape past piston rings
companion cyłinders: term given to pairs of cyłinders found in engines with even number of cyłinders
compression ratio: the ratio at which the air fueł gas mixture is compressed
dispłacement: refers to the vołume that the piston dispłaces in the cyłinder
firing order: The sequence in which the spark pługs fire in each cyłinder
łower end: Refers to the łocation at the bottom of the błock where the crankshaft and bearings are
łocated
TDC: Top Dead Center, referring to the łocation of the piston at the top of the stroke
transverse engine: term given to the engines in front wheeł drive vehicłes
[return to top]
WHAT’S NEW IN THIS CHAPTER
[Information to be added łater by author]
The fołłowing ełements are improvements in this chapter from the previous edition:
[return to top]
CHAPTER OUTLINE
In a simpłe one-cyłinder engine, the reciprocating (up-and-down) motion of the piston is changed
to usabłe rotary motion by the connecting rod and crankshaft. A fływheeł gives momentum to the
crankshaft between power strokes. Vałves controł the engine’s intake and exhaust. (PPT Słide 4)
During one four-stroke cycłe, the intake, compression, power, and exhaust strokes are compłeted.
This action takes 720°, or two crankshaft revołutions. (PPT Słide 5)
