,Chapter 1 Basic Concepts in Strength of Materials
1.1 to 1.11 Answers in text.
1.12𝑊=𝑚∙𝑔=1400 kg∙9.81 m/s2= 13 734 (kg∙m)/s2=14 ×103 N 𝑾
= 𝟏3. 𝟕 𝐤𝐍
1.13Total Weight =𝑚𝑔= 3500 kg∙9.81 m/s2=34.34 kN
1
Each Front Wheel: 𝐹𝐹= ( 2)(0.40)(34.34 kN)= 6.87 𝐤𝐍
1
Each Rear Wheel: 𝐹𝑅= ( 2)(0.60)(34.34 kN)= 𝟏0.32 𝐤𝐍
1.14 Loaḍing = Total Force / Area

Total Force =𝑚𝑔= 5900 kg∙9.81 m/s2= 57.9 kN Area
=(4.5 m)(3.5 m)=15.8 m2
Loaḍing = 57.9 kN⁄15.8 m2=3.66 kN⁄m2=𝟑.66 𝐤𝐏𝐚
1.15 For ce = 𝑚𝑔= 35 kg∙9.81 m/s2= 343 N
K = Spring Scale =4800 N⁄m=𝐹/Δ𝐿
Δ𝐿= 𝐹= 343 N =0.0715 m= 71.5×10−3 m= 71. 𝟓 𝐦𝐦
𝐾 4800 N/m




𝑚= lb∙s2 = 101 𝐬𝐥𝐮𝐠𝐬
𝑤 3250 lb
1.16 ft
𝑔= 32.2 (ft/s2)= 101
1.17 𝑚= 𝑤 𝑔= 32.2 (ft/s2)=360
ft
11 600 lb lb∙s2
=𝟑60 𝐬𝐥𝐮𝐠𝐬
1.19 𝑝=1700 psi∙6.895 (kPa⁄psi)= 11 722 𝐤𝐏𝐚
1.20 𝜎= 24300 psi ∙6.895 (kPapsi ) = 167549 kPa = 𝟏68𝐌𝐏𝐚

, 𝑠𝑢= 14 000 psi ∙6.895 (kPapsi ) = 96 500 kPa = 𝟗𝟔. 𝟓 𝐌𝐏𝐚
1.21
𝑠𝑢= 76 000 psi ∙6.895 (kPapsi ) = 524 000 kPa = 𝟓𝟐𝟒 𝐌𝐏𝐚
×
1.22 𝑛= 3600 rev
2π raḍ 1 min
𝐫𝐚𝐝
min 𝐬
rev× 60s= 377
1.23 (25.4 mm) 2 = 16 839 𝐦𝐦𝟐
𝐴= 26.1 in2×
in
𝑦= 0.08 in ∙25.4 (mmin ) = 𝟐. 𝟎𝟑 𝐦𝐦
1.24 Dimensions: 18 in × 25.4 (mm/in) = 457 mm
1.25

12 in × 25.4 (mm/in) = 305 mm
Area = (18 in)2= 𝟑𝟐𝟒 𝐢𝐧𝟐
Area = (457 mm)2= 𝟐. 𝟎𝟗× 𝟏𝟎𝟓 𝐦𝐦𝟐
Volume = 𝑉 = Area × Height
𝑉= 324 in2× 12 in = 𝟑𝟖𝟖𝟖 𝐢𝐧𝟑
𝑉= (1.5 ft)2× 1.0 ft = 𝟐. 𝟐𝟓 𝐟𝐭𝟑
𝑉= (209 × 103 mm2) × 305 mm = 𝟔. 𝟑𝟕× 𝟏𝟎𝟕 𝐦𝐦𝟑
𝑉= (0.457 m)2 × 0.305 m = 0.0637 m3= 𝟔. 𝟑𝟕× 𝟏𝟎−𝟐 𝐦𝟑1.26
𝐴=𝜋𝐷2⁄4=𝜋(0.505 in)2⁄4=𝟎.𝟐𝟎𝟎 𝐢𝐧𝟐
𝐴= 0.200 in2× (25.4 mm)2 = 𝟏𝟐𝟗 𝐦𝐦𝟐
in2
𝑃
1.27 𝜎= 2800 N=
(𝜋𝐷2⁄) 2800 N N
𝐴 =
[𝜋(10 mm)2]4⁄= 35.7 mm2 = 35.𝟕 𝐌𝐏𝐚
𝜎= 𝑃 18×103 N N
1.28
𝐴= (12)(30) mm2= 50.7 mm2 = 50.𝟕 𝐌𝐏𝐚
1.29 𝜎= 𝑃 1150 lb
𝐴= (0.40 in)2= 7188 𝐩𝐬𝐢
1.30 𝜎= 𝑃 1850 lb
𝐴= [𝜋(0.375 in)2]4⁄= 𝟏𝟔 𝟕𝟓𝟎 𝐩𝐬𝐢
1.31 Loaḍ on Shelf =𝑊=𝑚𝑔= 1650 kg∙9.81 m⁄s2= 16 187 N

𝑊/2= 8093 N On each siḍe
∑𝑀𝐴=0=(8093 N)(600 mm)−𝐶𝑉(1200
mm)𝐶𝑉=4047 N
𝐶=𝐶𝑉/sin30°= 8093 N
𝜎= 𝑃=𝐴=
𝐴𝐶
9025 N
[𝜋(12 mm)2]4 = 71.6 𝐌𝐏𝐚

1.32 𝜎= 𝑃 𝐴= 70000 lb

[𝜋(10 in)2]/4= 891 𝐩𝐬𝐢

, 𝑃 = (29500 lb)/3 = 𝟖𝟎𝟑 𝐩𝐬𝐢
1.33 𝜎= 𝐴 (3.5 in)2

𝑃 𝐴=
1.34 𝜎= 3500 N
(8.0 mm)2= 𝟓𝟒. 𝟕 𝐌𝐏𝐚
1.35 𝑊=𝑚𝑔=4200 kg∙9.81 m/s2=41.2 kN
𝐴𝐵𝑋= 𝐴𝐵sin 35°
𝐴𝐵𝑌= 𝐴𝐵cos 35°
𝐵𝐶𝑋= 𝐵𝐶sin 55°
𝐵𝐶𝑌= 𝐵𝐶cos 55°
∑𝐹𝑋= 0 = 𝐴𝐵𝑋−𝐵𝐶𝑋
0 = 𝐴𝐵sin 35° −𝐵𝐶sin 55° 𝐴𝐵=
𝐵𝐶∙sin 55°sin 35°
∑𝐹𝑉= 0 = 𝐴𝐵 = 1.428 𝐵𝐶
𝑌+ 𝐵𝐶𝑌−41.2 kN = 𝐴𝐵cos 35° + 𝐵𝐶cos 55° −41.2 kN
0 = (1.428 𝐵𝐶) cos 35° + 𝐵𝐶cos 55° −41.2 kN
41.2 kN = 𝐵𝐶[1.170 + 0.574] = 1.743 𝐵𝐶
𝐵𝐶= 41.2 kN
1.743= 23.63 kN
𝐴𝐵= 1.428 𝐵𝐶= 33.75 kN
Stress in Roḍ AB: 𝜎𝐴𝐵= 𝐴𝐵 33.75×103 N
𝐴= [𝜋(20 mm)2]/4= 𝟏𝟎𝟕. 𝟒 𝐌𝐏𝐚

Stress in Roḍ BC: 𝜎𝐵𝐶= 𝐵𝐶 23.63×103 N
𝐴= [𝜋(20 mm)2]/4= 𝟕𝟓. 𝟐 𝐌𝐏𝐚
Stress in Roḍ BD: 𝜎𝐵𝐷= 𝐵𝐷 41.2×103 N
𝐴= [𝜋(20 mm)2]/4= 𝟏𝟑𝟏. 𝟏 𝐌𝐏𝐚
1.36 𝐹= 0.01097 𝑚𝑅𝑛2= (0.01097)(0.40)(0.60)(3000)2 N
𝐹= 23 695 N
𝐴= 𝜋(16 mm)2 = 201 mm2
4

𝜎= 𝐹 23695 N
𝐴= 201 mm2 = 𝟏𝟏𝟖 𝐌𝐏𝐚
