Solution Manual for Control Systems Engineering, 8th
Edition by Norman S. Nise
, O N E
Introduction
ANSWERS TO REVIEW QUESTIONS
1. Guided missiles, automatic gain control in radio receivers, satellite tracking antenna
2. Yes - power gain, remote control, parameter conversion; No - Expense, complexity
3. Motor, low pass filter, inertia supported between two bearings
4. Closed-loop systems compensate for disturbances by measuring the response, comparing it
to the input response (the desired output), and then correcting the output response.
5. Under the condition that the feedback element is other than unity
6. Actuating signal
7. Multiple subsystems can time share the controller. Any adjustments to the controller can
be implemented with simply software changes.
8. Stability, transient response, and steady-state error
9. Steady-state, transient
10. It follows a growing transient response until the steady-state response is no longer visible.
The system will either destroy itself, reach an equilibrium state because of saturation in
driving amplifiers, or hit limit stops.
11. Transient response
12. True
13. Transfer function, state-space, differential equations
14. Transfer function - the Laplace transform of the differential equation
State-space - representation of an nth order differential equation as n simultaneous first-order
differential equations
Differential equation - Modeling a system with its differential equation
SOLUTIONS TO PROBLEMS
50 volts
1. Five turns yields 50 v. Therefore K = 1.59
= 5 x 2 rad
,
, 2 Chapter 1:
2.
Desired Temperature Voltage Actual
Fuel
temperatur difference difference temperature
flow
e
+ Amplifier
Thermostat Heater
and
- valves
3.
Desired Input Error Aileron Roll Roll
roll voltag voltag positio rat angl
+
controls
-
4.
Input
Speed
Desired voltag Actual
Error Motor
speed e spee
voltag and
transducer Amplifier d
+ e drive
system
- Dancer
Dancer
position
rsensor
dynamic
Voltage
proportiona
l
to actual speed
5.
Input Power Rod
voltag Error positio
Desired e voltag Motor n Actual
power e and powe
+ Amplifier
Transducer drive Reactor r
syste
-
Sensor &
transduce
Voltage
proportiona
l
to actual power
