Final Exam - INSY - 3305 - UTA - Dr. Koshy
Joseph-Vaidyan Questions with Detailed Verified
Answers
A(n) _____ is a formal way of representing how a business system interacts with its
environment.
Ans: use case
A scenario is the same as a(n) _____
Ans: path through a use case
Each use case describes _____ function(s) in which users interact with the system.
Ans: one
Jim has documented a use case that describes the functionality of a system as "To
compute gross pay, multiply the hours worked that are recorded on the time card
from the time clock by the hourly rate that is recorded in the employee master file
from the MS SQL server database." This is an example of a(n) _____ use case.
Ans: real
A(n) _____ use case is typically created early in the process of understanding the
system requirements as a way of documenting basic information about the use case.
Ans: overview
The importance level of a use case increases for all of the following characteristics of
the use case EXCEPT _____.
© Get it right 2025 Getaway - Stuvia US All rights reserved
,Click here for more: Scholars nexus
Ans: the technology is proven
The _____ relationship in use cases allows use cases to support the concept of
inheritance.
Ans: generalization
The event that causes a use case to begin is called a(n) _____.
Ans: trigger
Which of the following relationships describe the communication between the use
case and the actors?
Ans: association relationship
Which of the following relationships represent the extension of the functionality of
the use case to cover optional behavior?
Ans: extend relationship
Which of the relationship types in use cases enables functional decomposition?
Ans: include relationship
Individual steps in a use case should be written in the form _____.
Ans: Subject, Verb, Direct Object, Preposition, Indirect Object
If a use case becomes too complex, it should be _____.
Ans: decomposed into a set of use cases
© Get it right 2025 Getaway - Stuvia US All rights reserved
, Click here for more: Scholars nexus
The correct sequence of the major steps in creating use case diagrams is _____.
Ans: identify the major use cases, expand the major use cases, confirm the major use
cases, create the use-case diagram
When drawing the use-case diagram, an analyst should do the steps in this order:
_____.
Ans: identify the system boundary, draw the use cases on the diagram, place the
actors on the diagram, and draw the lines connecting the actors to the use cases
In estimating size and effort using use-case points, once the use-cases and use case
diagram have been created, the actors and use cases must be classified as _____,
_____, or ______.
Ans: simple, average, or complex
A(n) ___________ actor is a separate system that interacts with the current system
using standard communication protocols, such as TCP/IP, FTP, or HTTP, or an
external database that can be accessed using standard SQL.
Ans: average
A complex use case is one that has more than _____ unique transactions.
Ans: 7
An _____ of an analysis class represents a piece of information that is relevant to the
description of the class.
Ans: attribute
Which of the following would most likely not be an example of an attribute?
