AFAB 110 MIDTERM EXAM

QUESTION: The ___ block lists the assembly or sub assembly in which the part or the assembly
is to be used - ANSWER-Application block




QUESTION: Which of the following is typically not included in a basic parts list - ANSWER-The
finish




QUESTION: Which of the following is not one of the three regular views common in drafting
education - ANSWER-Rear view




QUESTION: ____ is the left to right measurement of an object from the vantage point of the
front view - ANSWER-Width




QUESTION: Which of the following is not one of the three principle projection planes common
in drafting education - ANSWER-Vertical




ALL THE BEST CHAMP!!
1

,Page 2 of 68


QUESTION: The ____ surface was perpendicular to one projection plane but inclined to other
two projection planes - ANSWER-Inclined




QUESTION: A flat surface is inclined to all three principle projection planes is known as as what
type of surface - ANSWER-Oblique Surface




Q; Which of the following are in thin short dashes that are spaced closely together - ANSWER-
hidden line




QUESTION: • • Print reading involves in elements of visualization and what - ANSWER-
Interpretation




QUESTION: In the United States the standardization of engineering values is established
through - ANSWER-ASME




QUESTION: Cutting plane lines are easily identifiable due to the appearance of what on both
ends - ANSWER-Arrow heads




QUESTION: Which of the following is not the types of lines used in dimensioning an object -
ANSWER-Brake lines




QUESTION: Engineering sheet sizes come in multiples of what - ANSWER-8 1/2 by 11
ALL THE BEST CHAMP!!
2

,Page 3 of 68




QUESTION: What does the acronym C.A.G.E stand for - ANSWER-Comercial And Government
Entities




QUESTION: ___ is a system where parallel lines are used to project the points of the 3d object
onto 2d projection plane - ANSWER-Orthographic projection




QUESTION: Molded and cast objected have rounded edges called ____ and rounds - ANSWER-
Fillets




QUESTION: Which of the following is not one of the three means aligned in a multi view
drawing can have - ANSWER-Curved surface tangent to a flat surface




QUESTION: A cylindrical object with an odd number of features is best described with what kind
of sectional view - ANSWER-Aligned




QUESTION: A ___ section is created when a small portion of a part is exposed to show the
interior construction - ANSWER-Broken out




QUESTION: Type of section where the section view is located out of projection - ANSWER-
Removed



ALL THE BEST CHAMP!!
3

, Page 4 of 68


QUESTION: In assembly drawings with multiple parts many of the parts may be shown in _____
sectional view and distinguished by orientating the section line at different angles and spacings
- ANSWER-Full




QUESTION: In an auxiliary view projected from a principle view is called what kind of auxiliary
view - ANSWER-Primary auxiliary view




QUESTION: An auxiliary view that shows only an inclined surface without showing the entire
object is refereed to as of what type of auxiliary view - ANSWER-Partial auxiliary view




QUESTION: Auxiliary view projected from the right side is called the ____ auxiliary view -
ANSWER-Width




QUESTION: A ____ auxiliary view projected from a primary auxiliary view - ANSWER-Secondary




QUESTION: A common reason to use auxiliary views is to show the true size and shape of a
____ surface - ANSWER-Inclined




QUESTION: Which of the following designations indicate unified nonstandard - ANSWER-U.N.S




QUESTION: Which of the following is not a method for representing threads - ANSWER-
Foreshortened
ALL THE BEST CHAMP!!
4
