NX DESIGN ASSOCIATE CERTIFICATION EXAM NEWEST 2025/2026
COMPLETE QUESTIONS AND CORRECT DETAILED ANSWERS (VERIFIED
ANSWERS) |BRAND NEW VERSION!!
Which command could you use to control the display or a specific feature based on
the value of an expression? - ANSWER-Suppress by Expression
What type of feature is used to define a new Sketch on a non-planar face? - ANSWER-
Datum Plane
How can you investigate the design intent of a sketch? - ANSWER-Vary a dimension
to see how the sketch changes
What command allows you to create a feature by rotating a section string around an
axis through a specified angle? - ANSWER-revolve
To create a datum plane at an angle to a face, what would you select? - ANSWER-
Select a face and datum axis or straight edge
Which of the following best describes an advantage of creating an edge blend
feature instead of creating fillet curves inside a sketch? - ANSWER-Can be edited,
suppressed, or deleted without affecting the sketch
Which one of these are not a type of hole you can create? - ANSWER-external
threads
,Which of the following cannot be selected to create Edge Blend features? - ANSWER-
sketch curves
What type of chamfer cannot be created? - ANSWER-two angle
What is an advantage of using a Hole feature instead of an Extrude? - ANSWER-A
Hole feature can be easily edited to change the form
You create a threaded hole in a lug for a specific size fastener. The resulting Hole
feature includes: - ANSWER-A single feature The hole, threads, and the entry and exit
chamfers
Why would you use a separate Thread command? - ANSWER-To create external
threads
You can create a chamfer feature or chamfer curves inside a sketch. What is a
potential advantage of creating chamfers in a sketch? - ANSWER-Your model history
will have fewer features
Why would you want to deactivate the Timestamp Order option in the Part
Navigator? - ANSWER-To view solid bodies in the model
When selecting a feature in the Part Navigator, what do the colors of the text above
and below the selected Feature mean? - ANSWER-The Parent- and Child relationships
When selecting a feature in the Part Navigator what color does the text of its
children features then become? - ANSWER-blue
, In the Part Navigator how can you list the parameters, expressions, and values of a
feature without using the Show Dimensions command? - ANSWER-Open the Details
Group
After using the Show Dimensions command on a sketch how do you erase the
temporarily-displayed dimensions from the graphics window? - ANSWER-Use the
Refresh command
By default, what happens to the child features when their parent feature is deleted? -
ANSWER-The child features are automatically deleted
Which Synchronous Modeling command can be used to change the radii of this
feature regardless of the feature history? - ANSWER-Resize Blend
Which Synchronous Modeling command can be used to transform faces in a linear
direction, angular direction, or from point to point? - ANSWER-Move Face
What type of models can synchronous modeling commands be used on? - ANSWER-
Both history based and non-parametric models
Synchronous modeling commands work best on what types of faces? - ANSWER-
Analytical faces
What is the primary workflow of synchronous modeling? - ANSWER-Edit non-
parametric models
Synchronous modeling workflows can be utilized to modify models that consist of: -
ANSWER-Synchronous modeling workflows can be utilized to modify models that
consist of:
