CCNA 2 Routing and Switching
Essentials v6.0 Final Exam Answers
(Option A)
A
R
U
LA
C
O
D
, A
R
Refer to the exhibit. Which highlighted value represents a specific destination network in the
routing table? - ANS 172.16.100.64
Refer to the exhibit. Assuming that the routing tables are up to date and no ARP messages are
ANS
U
needed, after a packet leaves H1 how many times is the L2 header rewritten in the path to H2? -
2
LA
Which type of static route is configured with a greater administrative distance to provide a
backup route to a route learned from a dynamic routing protocol? - ANS Floating static
route
Refer to the exhibit. Which route was configured as a static route to a specific networking using
the next-hop address? - ANS S 192.168.2.0/24 via 172.16.2.2
C
What network prefix and prefix-length combination is used to create a default static route that
will match and IPv6 destination? - ANS ::/0
O
A router has used the OSPF protocol to learn a route to the 172.16.32.0/19 network. Which
command will implement a backup floating static route to this network? - ANS ip route
172.16.32.0 255.255.224.0 S0/0/0 200
D
Refer to the exhibit. CUrrently router R1 uses an EIGRP route learned from Branch2 to reach
the 10.10.0.0/16 network. Which floating static route would create a backup route to the
10.10.0.0/16 network in the event that the link between R1 and Branch2 goes down? - ANS
ip route 10.10.0.0 255.255.0.0 209.165.200.225 100
Which statement describes a route that has been learned dynamically? - ANS It is
automatically updated and maintained by routing protocols.
Essentials v6.0 Final Exam Answers
(Option A)
A
R
U
LA
C
O
D
, A
R
Refer to the exhibit. Which highlighted value represents a specific destination network in the
routing table? - ANS 172.16.100.64
Refer to the exhibit. Assuming that the routing tables are up to date and no ARP messages are
ANS
U
needed, after a packet leaves H1 how many times is the L2 header rewritten in the path to H2? -
2
LA
Which type of static route is configured with a greater administrative distance to provide a
backup route to a route learned from a dynamic routing protocol? - ANS Floating static
route
Refer to the exhibit. Which route was configured as a static route to a specific networking using
the next-hop address? - ANS S 192.168.2.0/24 via 172.16.2.2
C
What network prefix and prefix-length combination is used to create a default static route that
will match and IPv6 destination? - ANS ::/0
O
A router has used the OSPF protocol to learn a route to the 172.16.32.0/19 network. Which
command will implement a backup floating static route to this network? - ANS ip route
172.16.32.0 255.255.224.0 S0/0/0 200
D
Refer to the exhibit. CUrrently router R1 uses an EIGRP route learned from Branch2 to reach
the 10.10.0.0/16 network. Which floating static route would create a backup route to the
10.10.0.0/16 network in the event that the link between R1 and Branch2 goes down? - ANS
ip route 10.10.0.0 255.255.0.0 209.165.200.225 100
Which statement describes a route that has been learned dynamically? - ANS It is
automatically updated and maintained by routing protocols.
