MSSC Comprehensive Quality Exam 2026/2027 Graded A+
(Questions with 100% Correct Answers)
The dimensions of raw material supplied by metal suppliers are described by the __________. - stock
size
Engineers sometimes use a ____________ to measure angles on a drawing. - Protractor
The three standard views of an object are____________. - top, front, right side
What type of drawing is shown? "All three views of an object." - Multiview
Which drafting style requires a computer? - CAD
An isometric drawing is a type of _________? - pictorial drawing
What dimension is indicated in the graphic? "Front view from bottom to top?" - Height
In manufacturing, a blueprint is also called what? - a technical drawing
Which of the following steps is not used in the glass box method? - Rotate object in a glass box
The number of views in a drawing __________. - is the fewest number that shows all the features
and dimensions
what is the order of precedence of lines in a drawing? - object, hidden, center
The holes to be drilled in the part are represented by _________. "Shows dashed lines through part"
- Hidden lines
What type best describes the line in the graphic? "reversed capital L pointing at the outside upright
leg line." - Object line
,Dimensions are used to specify the _________ and location of the features of an object. - size
a _________ dimension is described in inches per foot. - shaft taper
there are 60 minutes of arc in one _________. - degree
in the graphic shown, the two circles are _________. "there are two circles, one inside the other the
same plane and same distance apart around the circumference" - concentric
what features in the figure shown is a chamfer?
A- is a flat plane
b- seems to be an alignment pin
c- is a hidden hole
d-is the cut off edge of a 90 degree - D.
which type of feature is parallel to the surface being dimensioned? - Dimension Line
the length of the part shown in the drawing is _________ inches. "Lots of lines but look for the
overall lines" - 9-3/4
which of the following is NOT one of the six rules for dimensioning and object?
a-do not over dimension
b-Dimension in the view that most clearly shows the feature
c-dimension hidden lines
d-dimension an object completely - c-dimension hidden lines
The distance across the flats of the hex head shown in the part drawing is __________ inches. "find
the hex head and go from flat to flat. - 2-1/4
the hole shown in the graphic is a(n) __________ hole. "shows a hole with a noticeable shoulder
passing completely through part" - counterbore
, What type hole is shown in the figure? "dashes lines show hole with a squared edge as it steps down
a size" - counterbored
where would you look in a title block to see if there has been changes? - revision number
the material that will be used to create the gear is indicated in the part drawings title block to be
__________? "Look at the MATL: section" - cast iron
to establish on a drawing that 1/4 inch equals 1 inch, the designer would write ___________. - 1/4=1
the feature on a drawing is drawn 3 inches long and the scale is 1:4, what is the actual dimension on
the object? - 12"
What is the depth of the countersink in the image? "look at the countersunk hole and only pay
attention to the countersunk portion" - 0.12 inches
the part of the drawing that indicates that the drawing has the most up to date information on it is
_________. - drawing revision level
what is placed at the arrowheads of the sectional line to identify the cutting plane with the proper
sectional view? - Capital Letter
section line on a blueprint indicate _________. - a surface that has been cut
section lines in a sectional view are_________.
a-used to show the material from which the material was made?
b-patters set by the American National Standards Institute (ANSI)
c-used to represent the portion of the object which has been cut.
d-all of the above. - d-all of the above
a sectional view _________.
a-is an addition to the standard views drawn for a Multiview drawing
b-represents the internal features of a part when the hidden lines are not enough
