NCCER TEST 150 QUESTIONS AND WELL ELABORATED ANSWERS ALREADY A GRADED UPDATE|BRAND NEW{REVISED} The standard unit for measuring the cross sectional area of wire is the - ANSWERcircular mil the drawing scale is most likely to be found in the - ANSWER- drawing title block what is the minimum number of overload sensing units required for all three phase motors - ANSWER- 3 what is the resultant distance between center bends for a 10-inch offset at 15 degrees - ANSWER- 38.7 inches A UL listed rod type ground electrode must have minimum length of - ANSWER8'' in a circuit of pure capacitance, the current leads the voltage by - ANSWER- 90 degrees What is the symbol for the secondary side of a transformer - ANSWER- x Most common transformer on an industrial site - ANSWER- single phase step down applications for heat tracing systems with self regulating control include those requiring a narrow operating range and - ANSWER- temperature sensitive fluids with a row of 3-4'', 3-2'' and 1-1'' conduits on each side for a straight pullbox what is the minimum distance between the opposite side walls of the box - ANSWER32'' As the mechanical load increases on a squirrel
