, Term 1 Notes
Mechanical Systems
and Control
Key Terms
Levers: An Introduction
• Fulcrum (Pivot): The fixed point on
which the lever rotates.
A lever is a simple machine consisting
of a rigid bar that pivots around a point • Effort: The force applied to move
called the fulcrum. It helps lift or move the load.
a load with less effort by taking advantage • Load: The object or weight being
of mechanical principles. Levers are moved.
essential in understanding mechanical • c (MA):
systems and the principles of force The ratio of the load force to the
and motion. They provide foundational effort force. It indicates how much
knowledge for engineering, construction the lever reduces the effort needed
and daily problem-solving tasks. to lift a load.
Page 1 of 6 visit twinkl.com
,Types of Levers
First-Class Levers
• The fulcrum is positioned between the effort and the load.
• Depending on the position of the fulcrum, these levers may:
Characteristics • give a mechanical advantage (MA > 1);
• provide no mechanical advantage (MA = 1);
• require more effort than the load (MA < 1).
Examples
see-saw scissors crowbar pliers
Case Study on Mechanical Advantage:
• MA > 1: Fulcrum closer to the load (e.g. crowbar)
• MA = 1: Fulcrum equidistant between load and effort (e.g. see-saw with equal
weights)
• MA < 1: Fulcrum closer to the effort (e.g. scissors cutting thick material)
MA = 1
Page 2 of 6 visit twinkl.com
, Types of Levers
Second-Class Levers
• The load is positioned between the fulcrum and the effort.
Characteristics • Always provides a mechanical advantage (MA > 1) because
the load is closer to the fulcrum than the effort.
Examples
wheelbarrow nutcracker bottle opener
Third-Class Levers
• The effort is positioned between the load and the fulcrum.
• These levers never provide a mechanical advantage (MA < 1)
because the effort is always closer to the fulcrum than the
Characteristics
load.
• They are designed for speed and range of motion, not force
reduction.
Examples
tweezers fishing rods brooms
Page 3 of 6 visit twinkl.com
