A detailed drawing is an orthographic projection with... - ANSWERS-
Dimensions, notes, manufacturing specifications, everything necessary to
manufacture and inspect the part. (All of them)
Dimensions generally take the form of... - ANSWERS-Linear dimensions,
leader lines, angular dimensions, and notes (All of them)
Dimension and extension lines are thin so that they will not be mistaken
for ... lines. - ANSWERS-Visible
Which line type does not have arrowheads? - ANSWERS-Extension
Leader lines should not be ... - ANSWERS-Horizontal, Curved, & Vertical
Is a complete circle such as a hole dimensions by its diameter or radius. -
ANSWERS-Diameter.
A ______ is located in the circular view. - ANSWERS-Hole & cylinder.
The diameter of a ______ is given in the circular view. - ANSWERS-Hole
Dimesioning hidden lines under some circumstances is allowed. T or F? -
ANSWERS-False
, What is this symbol? Down arrow with line on top? - ANSWERS-Depth
What is this symbol? V - ANSWERS-Countersink
An orthographic projection is a representation of an object? - ANSWERS-Two
dimensional
In the US, is 1st or 3rd angle projection used as the standard? - ANSWERS-
3rd
The standard views used in an orthographic projection are - ANSWERS-
Front, Top, Right Side
the view that generally contains the least number of hidden lines. -
ANSWERS-Front
Are the front and right side views aligned vertically or horizontally? -
ANSWERS-Horizontally
To indicate line importance we draw lines using different line .... -
ANSWERS-Thickness
The thickest line type on a non-sectioned orthographic projection. -
ANSWERS-Visible.
If a hidden line and center line appear in exactly the same location on a
drawing, which one do you delete. - ANSWERS-Center Line
Are the front and top side views aligned vertically or horizontally? -
ANSWERS-Vertically
