This document contains condensed and in-depth notes on everything that is important for the EBN111 and EBN122 module. It contains summaries, equations, diagrams and previous test/exam questions and answers. This document contains all the content needed to ace electric circuits, as well as important examples to consolidate your knowledge. Everything covered in these notes is taken from the textbook 'Fundamentals of Electric Circuits'. EBN111 and 122 are 1st year engineering modules at the University of Pretoria with identical content.

Show more Read less
Institution
University Of Pretoria (UP)
Course
EBN111/122 (EBN122)

Content preview

EBN 111/122
FULL MODULE NOTES
COMPLETED EXAMPLES INCLUDED

,INDEX

Chapter 1: Basic Concepts

Basic Circuit Concepts

Circuit Elements (Active vs Passive)

Chapter 2: Basic Laws

Ohm’s Law

Short & Open Circuits

Conductance

Nodes, Branches & Loops 1
Series & Parallel Circuits 1
Kirchhoff’s Laws 1
Series Resistors & Voltage Division 1
Parallel Resistors & Current Division 1
Wye-Delta Transformations 2

,INDEX
Chapter 4: Circuit Theorems

Linearity

Superposition

Source Transformation

Thevenin’s Theorem

Norton’s Theorem

Maximum Power Transfer

Chapter 5: Amplifiers

Operational Amplifiers

Non-ideal & Ideal Amplifiers 6

Inverting Amplifiers 6

Non-inverting Amplifiers 6

Summing Amplifiers 7

Difference Amplifiers 7
7

, INDEX
Equivalent Inductance
Chapter 7: Sinusoids & Phasors

Sinusoids

Complete Number System

Phasors

Phasors Relationship for Circuits Elements

Impedance & Admittance 1

Operational Amplifiers 1

Chapter 8: Sinusoidal Steady-state Application 1
