Answer ALL questions in the space provided. The use of non-programmable electronic calculators
is allowed.

Scenario

• An engineering company issued a call for applications for electronic technicians.
• The applicants were given the following test to assess their knowledge in electronic circuit
design.

Question 1 K-1 (6 marks)

a. Categorise the following materials as insulators or conductors by filling in Table 1 below.

Copper Rubber Wood Bronze
Porcelain Oil Silver Steel

Table 1: Conductors or Insulators.

Conductors Insulators




(2)

b. Define the term semi-conductor.

__________________________________________________________________________

__________________________________________________________________________

__________________________________________________________________________

__________________________________________________________________________

_______________________________________________________________________ (2)


c. One of the technicians measured the resistance of two wires made up of the same material. He noted
that the resistance is different in each case. State the TWO parameters affecting the resistance of
the wires.

Parameter 1:

_______________________________________________________________________ (1)

Parameter 2:

_______________________________________________________________________ (1)
6
Page 2 of 16

, SEC37/s2.22s
DO NOT WRITE ABOVE THIS LINE



Question 2 C-1 (12 marks)

a. Describe the relationship between resistance, voltage and current. Write down the equation
and the SI unit for each parameter.

__________________________________________________________________________

__________________________________________________________________________

__________________________________________________________________________

__________________________________________________________________________

__________________________________________________________________________

__________________________________________________________________________

__________________________________________________________________________

_______________________________________________________________________ (4)


b. Figure 1 shows the measurements of current and voltage across a resistor. Determine the
resistance from the given VI graph. Show all your workings.


VI graph
1.2


1


0.8
Voltage (V)




0.6


0.4


0.2


0
0 0.5 1 1.5 2 2.5
Current (mA)

Figure 1: VI graph of an ohmic component



__________________________________________________________________________

__________________________________________________________________________

__________________________________________________________________________


Page 3 of 16
