Welding Print Reading - Final EXAM
Welding Print Reading - Final EXAM
Welding Print Reading - Final EXAM
Welding Print Reading - Final EXAM
,Which of the following is not an example of a standard finishing method?
drilling
A graphic assembly of elements needed to fully specify weld requirements
on a print is a ____.
welding symbol
,The central element of a welding symbol, which provides a place for all
other elements, is the ____.
reference line
The part of a welding symbol that depicts the cross-sectional shape of a
weld or joint is the ____.
weld symbol
Information is called out in the tail of a welding symbol using a(n) ____.
notation
, The only required elements of a welding symbol are the ____.
reference line and arrow
Which of the following are standard finishing method?
Grinding, Machining, & Rolling
Which of the following is not an example of a contour for the finished
shape of a weld?
square
